Factory Wholesales SAKO SUNPOLO High Frequency Inverter 3kw24V Pure Sine Wave Power 3000W Inverter with WIFI
- Category: >>>
- Supplier: Shenzhen Sako Solar Co. Ltd.
Share on (1600345428210):
Product Overview
Description
Rated Power | SUNPOLO 3KW | SUNPOLO 5KW | ||
INPUT | ||||
Voltage | 230VAC | |||
Voltage Range | 176-280 VAC at 100% load | |||
110-280 VAC at 50% load | ||||
Frequency Range | 50Hz/60Hz(Auto sensing) | |||
OUTPUT | ||||
AC Voltage Regulation(Batt.Mode) | 230VAC±3% | |||
Surge Power | 6400VA for 5 sec | 10400VA for 5 sec | ||
Efficiency(Peak) | >95% ( Rated R load, battery full charged | |||
Transfer Time | 10ms typical (UPS) | |||
20ms typical (Appliances) | ||||
Waveform | Pure sine wave | |||
BATTERY | ||||
Battery Voltage | 24 VDC | 48 VDC | ||
Floating Charge Voltage | 27 VDC | 54 VDC | ||
Overcharge Protection | 32 VDC | 64 VDC | ||
SOLAR CHARGER & AC CHARGER | ||||
Solar Charger Type | MPPT | |||
Maximum PV Array Open Circuit Voltage | 500VDC | |||
Maximum PV Array Power | 4000W | 5000W | ||
MPP Range@ Operating Voltage | 120-450VDC | 120-450VDC | ||
Maxmum Solar Charge Current | 80A | 80A | ||
Maximum AC Charge Current | 60A | |||
PHYSICAL | ||||
Products Dimension,D X W X H (mm) | 492*303*129 | 456*303*147 | ||
Product Net Weight(kgs) | 10 | 12 | ||
Packing Dimension,D X W X H (mm) | 570*395*215, 1PC/CTN | 530*377*217,1PC/CTN | ||
Product Net Weight(kgs) | 11.5 | 13.5 | ||
Communication Interface | Removable OTG USB/RS232/RS458/BLE/Dry-contact,BMS interface, | |||
OPERATING ENVIRONMENT | ||||
Humidity | 5% to 95% Relative Humidity(Non-condensing) | |||
Operating Temperature | -10℃ to 50℃ | |||
Storage Temperature | -15℃ to 60℃ | |||
*Product specifications are subject to change without further notice | ||||
Company Profile
TEDEPE Solar is a new PV factory founded in the year of 2016 , we have a number of experienced professionals who have been eagaged in this field with product development , production and marketing for more than 10 years . TEDEPE Solar located in Changping Town ,Dongguan city which is the most famous manufacturing city ,from Guangzhou or Shenzhen city to Changping Town by high speed train only 30 minutes .
TEDEPED Solar with most advanced equipments of Tabber and Stringer Solar Machine,two laser cutting machine ,two solar Simulator ,one Auto Selection Solar Cell Tester,one of line EL Detector ,two solar panel Tester and Three Laminationg Machine .
SAKO POWER has three branch manufacturers,Stabilizer manufacturer was located in Wenzhou city ,UPS and Inverter was located in Shenzhen City,DC power supply and switching power supply was located in Hangzhou city ,sako is committed to provide defferent location advantages to customers and each manufacturer.We have professional marketing engineering teams to dedicate in product development.Sako Power guarantees reliable product development and consistent manufacturing quality ,from raw materials to finished products ,and deeply respects its delivery deadlines.
Sako Powre is a trulty reliable company,with its personnel providing in service ,innovation and growth .Sako Power's professional team is always be one of the best sincerely and realiable cooperators in global powre market .
SAKO Enterprise ,like a pearl,shinning so ever brightly in the power supply industry of China.
Leading OEM/ODM Manufacturer in Solar System ,Solar Inverter ,Home Inverter ,UPS,Frequency Inverter ,switching power supply ,Stabilizers and AVR.
TEDEPED Solar with most advanced equipments of Tabber and Stringer Solar Machine,two laser cutting machine ,two solar Simulator ,one Auto Selection Solar Cell Tester,one of line EL Detector ,two solar panel Tester and Three Laminationg Machine .
SAKO POWER has three branch manufacturers,Stabilizer manufacturer was located in Wenzhou city ,UPS and Inverter was located in Shenzhen City,DC power supply and switching power supply was located in Hangzhou city ,sako is committed to provide defferent location advantages to customers and each manufacturer.We have professional marketing engineering teams to dedicate in product development.Sako Power guarantees reliable product development and consistent manufacturing quality ,from raw materials to finished products ,and deeply respects its delivery deadlines.
Sako Powre is a trulty reliable company,with its personnel providing in service ,innovation and growth .Sako Power's professional team is always be one of the best sincerely and realiable cooperators in global powre market .
SAKO Enterprise ,like a pearl,shinning so ever brightly in the power supply industry of China.
Leading OEM/ODM Manufacturer in Solar System ,Solar Inverter ,Home Inverter ,UPS,Frequency Inverter ,switching power supply ,Stabilizers and AVR.
FAQ
1. who are we?
We are based in Guangdong, China, start from 2016,sell to Mid East(30.00%),Southeast Asia(10.00%),Southern Europe(10.00%),Central America(10.00%),Eastern Asia(5.00%),North America(5.00%),South Asia(5.00%),Africa(5.00%),South America(5.00%),Domestic Market(4.00%),Northern Europe(4.00%),Oceania(3.00%),Western Europe(2.00%),Eastern Europe(2.00%). There are total about 301-500 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Solar Panel,Solar System,Solar Inverter,Solar Charge Controller,lithium ion batteries
4. why should you buy from us not from other suppliers?
Tedepe Solar belong to SAKO GROUP cooperate with Haier and large-scale production line with advanced equipment ,the production line capacity is 1day 2 40HQ Containers.
Sako established in 1993 in China has 23 years rich experience in dealing with OEM&ODM.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
We are based in Guangdong, China, start from 2016,sell to Mid East(30.00%),Southeast Asia(10.00%),Southern Europe(10.00%),Central America(10.00%),Eastern Asia(5.00%),North America(5.00%),South Asia(5.00%),Africa(5.00%),South America(5.00%),Domestic Market(4.00%),Northern Europe(4.00%),Oceania(3.00%),Western Europe(2.00%),Eastern Europe(2.00%). There are total about 301-500 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Solar Panel,Solar System,Solar Inverter,Solar Charge Controller,lithium ion batteries
4. why should you buy from us not from other suppliers?
Tedepe Solar belong to SAKO GROUP cooperate with Haier and large-scale production line with advanced equipment ,the production line capacity is 1day 2 40HQ Containers.
Sako established in 1993 in China has 23 years rich experience in dealing with OEM&ODM.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
Products Description
SUNPOLO SERIES HYBRID SOLAR INVERTER WITH MPPT INSIDE,HIGH FREQUENCY
MAIN FEATURES
1. With MPPT solar charger controller built inside, Max PV input power reach to 5000W.
2. Wide PV input range (Up to 450Vdc), can work without battery during the day time.
3. Built-in wifi for mobile monitoring (requires App)
4. Optional for parallel operation up to 9 units for 5KW
5. Selectable charging current based on applications
6. Configurable AC/Solar input priority via LCD setting
7. Smart battery charger and management for optimized battery performance.Compitable with LI Ion, LiFePo4 and ect.
7. Smart battery charger and management for optimized battery performance.Compitable with LI Ion, LiFePo4 and ect.
8. 5KW Support Self-consumption and feed into the grid. Export excess pv power to grid via setting
9. Auto restart while AC is recovering, auto charge and switch, unattended operation
10. Various communication such as WIFI/RS485/RS232 optional.
11. High Efficient DC-To-AC Conversion.Minimizing Energy Loss and self power consumption
12. All around protection functions: Overload/short circuit
protection/high voltage/low battery voltage/high temerature,etc.
protection/high voltage/low battery voltage/high temerature,etc.
13. 5KW Optional for self-consumption and feed into the grid by
setting.
setting.
