Factory Price Automatic Tooth Pick Stick Bbq Skewer Processing Production Line Bamboo Toothpick Making Machine For Sale

Product Overview

Description

Factory Price Automatic Tooth Pick Stick Bbq Skewer Processing Production Line Bamboo Toothpick Making Machine For Sale

Process: original bamboo, saw cut, cut bamboo strips, knotting and widening opening, forming, bleaching, drying, cutting, fixed length, polishing, finishing sharpening, packaging and delivery.

The above 10 sets are a production line of bamboo toothpicks, with an output of about 800,000 in 8 hours and about 100 kg in dry toothpicks. If you need to increase the output, you can add one more toothpick forming machine.



Technical parameters:

Name	Model	Motor power (kw)	Weight (kg)	Dimension(mm)
Bamboo sawing machine	DN111	1.5	60	750*600*1300
Bamboo dissection machine	DN102	3.0	530	3000*950*1200
Bombined flaker	DN103	3.0	260	1180*680*1100
Bamboo filament shaping machine	DN104	9.1	400	1020*690*1050
Bamboo filament set-size machine	DN105	0.75	75	1500*650*990
Polishing machine	DN278	2	80	900*600*800
Toothpick set-size machine	DN80	0.55	110	1050*1050*1200
Toothpick finishing machine	DN113	0.55	65	1050*900*850
Toothpick sharpened machine	DN268	1.65	160	950*650*1050
Knife Sharpener	DN112	0.55	50	450*400*870

1. Bamboo Sawing Machine: It is used to cut bamboo into certain length.
2. Bamboo Cutting Machine: This machine is used to split the bamboo into strips.
3. Fixed Width Slicer: Used for width and thickness setting and knot removing, separating green layer from yellow layer, ensures the surface quality of processed material.
4. Bamboo Stick Shaping Machine: This machine is used for making thick bamboo strip into thinner one.
5. Bamboo Stick Size Setting Machine: Special equipment for bamboo stick or wood stick fixed size cutting, especially for round stick size set.
6. Bamboo Toothpick Cutting Machine: Length setting for bamboo toothpick
7. Toothpick Polishing Machine: It is to make the surface of toothpicks more smooth.
8. Toothpick Finishing Machine: Dedicated equipment for tidying toothpicks. Through vibration, tidy the irregular toothpicks to achieve the effect of packaging.
9. Toothpick Sharpening Machine: Used for sharpening bamboo toothpicks.
10. Blade Sharpening Machine: Used for blade grinding

picture:
