200Ton Chinese Manufacturers wholesale high quality and high performance Low Noise Medium Temperature Water Cooling Tower
- Category: Cooling Tower >>>
- Supplier: Zhejiang Lianfeng Cooling Tower Co. Ltd.
Share on (1600347378686):
Product Overview
Description
Product Description
Round General Series Glass Fibre Reinforced Plastic Cooling Tower Outline and Foundation Illustration
Product Characteristic
1. Shape of bottle design，with minimum windward capacity.
2. Light and delicate structure, convenient assembly, strong and durable, good cooling effect.
3. The tower body is made of high-strength FRP composite material, lightweight and high strength,aging resistance,erosion-resistance, no distortion and no fading.
4. Recoil type automatic rotation water distribution, low water supply pressure, small water head loss,and uniform water
distribution.
distribution.
5. Using hot dip galvanized steel support,strong corrosion resistant.
Product Paramenters
Type | Specifications | cooling water(m³/h) | fan diameter(mm) | motor power(Kw) | Inlet water pressure(KPa) |
Medium temperature ultra low noise series BLSS(II) | 50 | 50 | 1200 | 2.2 | 32 |
75 | 75 | 1500 | 3 | 33 | |
100 | 100 | 1800 | 4 | 34 | |
150 | 150 | 2000 | 5.5 | 39 | |
200 | 200 | 2800 | 7.5 | 40 | |
250 | 250 | 2800 | 7.5 | 41 | |
300 | 300 | 3400 | 11 | 44 | |
350 | 350 | 3400 | 11 | 45 | |
400 | 400 | 4200 | 15 | 48 | |
500 | 500 | 4600 | 18.5 | 52 | |
600 | 600 | 5000 | 30 | 55 |
Type | Specifications | dry weight(Kg) | wet weight(Kg) | dB（A） | ||
Dm | 16m | |||||
Medium temperature ultra low noise series BLSS(II) | 50 | 750 | 1030 | 56 | 38 | |
75 | 970 | 1390 | 58 | 42 | ||
100 | 1490 | 2050 | 59 | 44.5 | ||
150 | 1910 | 2750 | 60 | 47 | ||
200 | 2830 | 3940 | 61 | 49 | ||
250 | 3570 | 5250 | 62 | 51 | ||
300 | 3950 | 5630 | 63 | 53 | ||
350 | 5080 | 7300 | 63 | 53 | ||
400 | 5660 | 7880 | 64 | 55 | ||
500 | 6680 | 9460 | 65 | 57 | ||
600 | 7700 | 10200 | 65 | 58 | ||
Meteorological conditions for product design Inlet and outlet tower water temperature
Atm pressure:P=1.004 x 10^5Pa(753mmHg) 43℃~33℃
Dry bulb temperature:θ=31.5℃ Wet bulb temperature:τ=28℃
Details Images
Related Products
Packing&Shipping
After Sales Service
1. The products sold by the company are guaranteed for one year and lifetime service.
2. After delivery of the equipment, the company will provide professional installation or technical guidance for installation.
3. The company can provide equipment operation and commissioning services, as well as on-site training and guidance for operators.
4. The after-sales service hotline is open 24 hours a day, and professional technicians are provided to serve you.
5. The company provides annual inspection or international remote video inspection for free.
Company Introduction
The four technology advantages that Lianfeng has are:high cooling effect.low noise,low electric consumption,and long life expectancy.
