Product model | A20 | ||||||||||||||||
Imaging sensor | 1/2.7-Inch CMOS Digital Image Sensor | ||||||||||||||||
Pixel Size | 3.0um*3.0um | ||||||||||||||||
Image area | 5.808mm*3.288mm | ||||||||||||||||
Active Pixels | 1920(H)*1080(V) | ||||||||||||||||
Video resolution | 1920*1080 @30fps MJPEG 1280*960 @30fps MJPEG 1280*720 @30fps MJPEG 800*600 @30fps MJPEG 640*480 @30fps MJPEG 320*240 @30fps MJPEG | ||||||||||||||||
Video format | YUY2/MJPG | ||||||||||||||||
SNR | 38.6dB | ||||||||||||||||
Dynamic range | 72dB | ||||||||||||||||
Viewing Angle | D=74º/H=67º/V42º | ||||||||||||||||
TV distortion | <-0.5% | ||||||||||||||||
Minimum illumination | <10Lux | ||||||||||||||||
Focal Length | 4.43mm | ||||||||||||||||
F/NO | 2.0mm | ||||||||||||||||
Focus type | Automatic Focus | ||||||||||||||||
Minimum Object Distance | 70mm | ||||||||||||||||
Shutter type | Electronic rolling shutter/Frame exposure | ||||||||||||||||
Adjustable parameter | Brightness, contrast, sharpness, white balance,contrast exposure gain | ||||||||||||||||
Low brightness compensation | Auto | ||||||||||||||||
Image processing | Automatic exposure/automatic white balance/Automatic Focus | ||||||||||||||||
Microphone | Built-in full directional high sensitivity low noise cancelling microphone | ||||||||||||||||
Listening range | Speak normally within 3 meters and the voice is clear and recognizable | ||||||||||||||||
Frequency spectrum | 300HZ-8KHZ | ||||||||||||||||
Audio Sample Rate | Monaural 16bit 8KHZ 16KHZ 32KHZ 48KHZ | ||||||||||||||||
Audio coding format | PCM,compatibility UAC1.0 | ||||||||||||||||
Compatible system | Windows XP ,Windows 7 Windows 8, Windows 10,Android V5.0 Or higher version OS,MAC OS10.6Or higher version | ||||||||||||||||
USB interface type | USB2.0 High-speed and Full-Speed transceiver Applicable to UVC1.1 or 1.5 | ||||||||||||||||
Support OTG protocol | USB2.0 OTG | ||||||||||||||||
Power Consumption | 2W | ||||||||||||||||
Operating temperature | -10-45℃ | ||||||||||||||||
HSF&Safety | ROHS |
