  • XB 7120 high speed fast read factory direct selling 2D Mini portable fixed qr code scanner cmos barcode scanner
XB 7120 high speed fast read factory direct selling 2D Mini portable fixed qr code scanner cmos barcode scanner
XB-7120 high speed fast read factory direct selling 2D Mini portable fixed qr code scanner cmos barcode scanner
XB-7120 high speed fast read factory direct selling 2D Mini portable fixed qr code scanner cmos barcode scanner
XB-7120 high speed fast read factory direct selling 2D Mini portable fixed qr code scanner cmos barcode scanner
XB-7120 high speed fast read factory direct selling 2D Mini portable fixed qr code scanner cmos barcode scanner

XB 7120 high speed fast read factory direct selling 2D Mini portable fixed qr code scanner cmos barcode scanner

Share on (1600349298634):


Price:$30.00 - $33.00

Quantity:


Product Overview

Description


 high speed fast read 2D Mini portable fixed qr code reader scanner


cmos barcode scanner


Model:XB-7120





Product Description


XB-7120 Fixed mount scanner series is delivering fast, high-volume hands-free scanning of virtually any barcode— including 1D, 2D code. No matter what type of barcode is presented, or whether it is printed on paper, or displayed on a mobile phone screen, the XB-7120 series provides fast, accurate scanning in a tiny footprint that fits in the most space-constrained areas.





Product Features :


--Hands-free convenience and extraordinary speed


--Fits in the smallest of spaces


--This device can be mounted just about anywhere-attached to the register or under  the counter or airport gate.


--Flexible and easy to integrate


--Be used as a standalone scanner


--High-Volume Scanning





Product Details




































































































Specification



Performance Parameters



Light Sources



617nm LED Aimer, White LED



Supported symbologies



1D: EAN, UPC, Code 39, Code 93, Code 128, UCC/EAN 128, Codabar,


Interleave 2 of 5, ITF-6, ITF-14, ISBN, ISSN, MSI-Plessey, GS1 Databar,


GS1 Composite Code, Code 11, Industrial 25, Standard 25, Plessey,


Matrix 2 of 5.


2D: QR Code, Data Matrix, PDF417, Micor PDF417, Aztec,


Micor QR, Maxicode, Hanxin Code.



Scan Type



Image CMOS



Resolution



640*480



Scan Angle



Yaw ±60°,Rotation 360°,Pitch ±60°



Precision



≥5mil



Bit Depth of field



EAN13  50mm-200mm(13mil);


QR  25-240mm(20mil);


PDF147  30-130mm(6.67mil)



Error Rate



Less than 1/5million



Interface



USB-HID, USB-COM, RS232



Physical  Parameters



Dimensions



52mm*56.5mm*25mm



Weight



60g



Material



ABS+PC



Environmental Parameters



Operating Temperature



20℃ ~ 50℃



Storage Temperature



-40℃ ~ 70℃



Humidity



5% to 95% RH (Non-condensing)



Shock Resistance



Withstands multiple times 3 meters drops to concrete



Electrical Parameters



Working Voltage



DC5V ±5%



Operating Current



170mA



Standby Current



USB 25mA; RS232 2uA






Packaging & Shipping



  • Fast Shipping from Guangzhou Xunbao barcode scanners Factory

  • Item shipped in 3-10working days after payment is received depends on the quantity of the order.

  • Item shipped by UPS,FEDEX,DHL,TNT and others,depending onf size and weight of total order

  • Deliver time:24hours from stock order,production order within 3-5days.

  • Tracking number will be sent to you as soon as when shipped the goods.jpg





Company Information


We are barcode scanner manfacturer in Guangzhou, which qualified by ISO9001:2008,all products passed CE,RoHS,and FCC etc.
















Safety Standards
EMCCE EN55022 B, FCC Part 15 Class B, SGS,IP54 Waterproof Test.
Laser safetyIEC 60825-1 Class 1















Our Services


Technical support



  1. Provide the necessary professional traning online or offline

  2. Comprehensive technical support provide pre-sales&after-sales

  3. Presentation&promotion of the new inonvative products


Spare parts policy



  1. Provide certain spare parts in every order shipment as required

  2. Provide free maintenance or replacement spare parts within the given warranty period

  3. Provide free maintenance technology and spare parts chargeable under out of warranty


Products service



  1. Provide the pre-sales,in-sales and after-sales services

  2. Provide all technical documents as required

  3. 2 years warranty for all of our products


Value-added services



  1. Provide long time maintenance services

  2. Provide extended warranty as required

  3. Provide the regular routine maintenance services





FAQ


1:Do your company is a trading agent or manufacturer?


   We are professional manufacturer of all kinds of Barcode Scanner with own factory


2.What about the warranty of this Corded Barcode Scanner?


   2 years warranty on the Barcode Reader, 6 month on the cable


3.What is the minimum order of this Barcode Reader?


   The MOQ is 1pc with our logo


4.Do you have stock products to sell?


  Yes,and we also work on OEM/ODM orders,like printing with your brand&label design


5.What's your products range?


--Laser barcode scanner


--Wireless barcode scanner


--Omni-directional barcode scanner


--CCD barcode scanner


--2D barcode scanner
