HT16K33 28SOP RAM Mapping 16x8 LED Controller Driver with keyscan 28SOP HT16K33
- Category: >>>
- Supplier: Shenzhen Baolaiwei Technology Co. Ltd.
Share on (1600352844893):
Product Overview
Description
Specification
item | value |
Model Number | HT16K33 |
Type | integrated circuit |
Place of Origin | Original |
D/C | New |
Package | 28SOP |
Condition: | New Original 100% |
Skype | Morgan1204 |
Whatsapp | 86 13718918414 |
Email | Morgan@axtekic.com |
Product Description
HT16K33 RAM Mapping 16*8 LED Controller Driver with keyscan
The HT16K33 is a memory mapping and multi-function LED controller driver. The max. Display
segment numbers in the device is 128 patterns (16 segments and 8 commons) with a 13*3 (MAX.)
matrix key scan circuit. The software configuration features of the HT16K33 makes it suitable
for multiple LED applications including LED modules and display subsystems. The HT16K33 is
compatible with most microcontrollers and communicates via a two-line bidirectional I2C-bus.
The HT16K33 is a memory mapping and multi-function LED controller driver. The max. Display
segment numbers in the device is 128 patterns (16 segments and 8 commons) with a 13*3 (MAX.)
matrix key scan circuit. The software configuration features of the HT16K33 makes it suitable
for multiple LED applications including LED modules and display subsystems. The HT16K33 is
compatible with most microcontrollers and communicates via a two-line bidirectional I2C-bus.
* Operating voltage: 4.5V~5.5V
* Integrated RC oscillator
* I2C-bus interface
* 16*8 bits RAM for display data storage
* Max. 16 x 8 patterns, 16 segments and 8 commons
* R/W address auto increment
* Max. 13 x 3 matrix key scanning
* 16-step dimming circuit
* Selection of 20/24/28-pin SOP package types
* Integrated RC oscillator
* I2C-bus interface
* 16*8 bits RAM for display data storage
* Max. 16 x 8 patterns, 16 segments and 8 commons
* R/W address auto increment
* Max. 13 x 3 matrix key scanning
* 16-step dimming circuit
* Selection of 20/24/28-pin SOP package types
