hydraulic guillotine shearing machine QC12Y 4*2500mm with E21S
- Category: Shearing Machine >>>
- Supplier: Anhui,Zhongwang,Precision,Machinery,Manufacturing,Co.,Ltd.
Share on:
Product Overview
Description
Product Information
Hydraulic guillotine shearing machine QC12Y-4*2500mm with E21S
Qc12y series CNC hydraulic shearinf machine consists of frame, blade, rear stop, rapid blade, gap adjustment mechanism, hydraulic system, electrical system components, racks welded by right and left wall board and upper and lower support block. After eliminate stress to ensure the rack has sufficient rigidity and strength.
Both of sides wall board had two cylinders, blade install on right and left wall board, Under the hydraulic system, drive blade to do swing arc action. On blade racks, there are upper blade, shear with lower blade which on work table. Upper blade surface is arc surface, ensure consistency when shear the plates. To ensure the quality of the workpiece cutting. The great advantage of the machine is convenient and quick.
Rear stop used for supporting, screw gauge beam driven and do forward and backward action, has high precision.
Both of sides wall board had two cylinders, blade install on right and left wall board, Under the hydraulic system, drive blade to do swing arc action. On blade racks, there are upper blade, shear with lower blade which on work table. Upper blade surface is arc surface, ensure consistency when shear the plates. To ensure the quality of the workpiece cutting. The great advantage of the machine is convenient and quick.
Rear stop used for supporting, screw gauge beam driven and do forward and backward action, has high precision.
Hydraulic swing beam shear | Type | shearing thickness | shearing length | cutting angel | materail strength | stopper adjust rangge | stroke times | main power |
QC12K-4*2500 | 4 | 2500 | 1°30' | ≤450 | 20-500 | 16 | 5.5 | |
QC12K-4*3200 | 4 | 3200 | 1°30' | ≤450 | 20-500 | 13 | 5.5 | |
QC12K-6*4000 | 6 | 4000 | 1°30' | ≤450 | 20-600 | 9 | 7.5 | |
QC12K-6*6000 | 6 | 6000 | 1°30' | ≤450 | 20-800 | 5 | 11 | |
QC12K-8*3200 | 8 | 3200 | 1°30' | ≤450 | 20-500 | 8 | 7.5 | |
QC12K-12*3200 | 12 | 3200 | 2° | ≤450 | 20-600 | 10 | 18.5 | |
QC12K-16*2500 | 16 | 2500 | 2°30' | ≤450 | 20-600 | 10 | 18.5 | |
QC12K-16*4000 | 16 | 4000 | 2°30' | ≤450 | 20-800 | 10 | 18.5 | |
QC12K-20*3200 | 20 | 3200 | 3° | ≤450 | 20-800 | 8 | 22 |
Main Configuration | ||
Main motor | Siemens, Germany | |
Electrics | Schneider, France | |
Hydraulic valve | Rexroth, Germany | |
Oil Pump | Sunny, U.S.A | |
Controller | E21s ESTUN, MD11 | |
Foot switch | Karcon, South Korea | |
Anhui Zhongwang Precision Machinery Manufacturing Co., Ltd.
Anhui Zhongwang Precision Manufacturing Machinery Co., Ltd. (formerly known as State-owned Dangtu Machinery Factory) was established in 1978. Now the company specializes in the research and development of bending machines, shears and other mechanical equipment. Production.
The main products cover: QC11Y, QC12Y, WC67Y, WE67K, W11, J23, J21s, J21S, Q35Y and more than 20 series, more than 200 varieties of large, medium and small ordinary CNC shears,Ordinary CNC bending machine, electro-hydraulic servo bending machine, press. It is widely used in automobile manufacturing, communication, computer and other fields. The company has its own scientific research and development institution, and has strong domestic product research and development capabilities.
To our customers: Your demand for quality is the driving force for our efforts. May our products and efforts bring you the joy of success!
The main products cover: QC11Y, QC12Y, WC67Y, WE67K, W11, J23, J21s, J21S, Q35Y and more than 20 series, more than 200 varieties of large, medium and small ordinary CNC shears,Ordinary CNC bending machine, electro-hydraulic servo bending machine, press. It is widely used in automobile manufacturing, communication, computer and other fields. The company has its own scientific research and development institution, and has strong domestic product research and development capabilities.
To our customers: Your demand for quality is the driving force for our efforts. May our products and efforts bring you the joy of success!
