67.2v5a 336w li ion battery charger ac 100-240v to dc 67.2v 5a chargers batteries power supply for electric motorcycle
- Category: Charger >>>
- Supplier: Dongguan,Intai,Power,Supply,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
Description
The 67.2v 5a battery charger incorporates a 50/35 transformer and effective thermal management in power electronics to achieve high power density. The 67.2v 5a battery charger is not only powerful, a multi-stage charge profile is implemented to monitor the charging process, maximize battery capacity, optimum battery life and reliability. Safety is a priority. The 67.2v 5a battery charger is designed for safe charging to prevent fire hazard by avoiding overcharging your batteries in any abnormal conditions.
Product Specificatio
Input | Voltage Range | 90-264VAC |
Frequency Range | 47-63Hz | |
Standby Power | <0.21W | |
Average Efficiency | >88% | |
Power Factor (Typ) | >0.9 | |
Output | Output Voltage | 67.2V±5% |
Rated Current | 5A | |
Ripple & Noise | 150mV | |
Hold Up Time | >15mS(115/230Vac input at full load) | |
Transient Response(Typ) | 0.5mS for 50% load change | |
Line Regulation | ±2% max | |
Load Regulation | ±5% max | |
Protection | Over Current | 150% of rated output current, hiccup mode, auto recovery |
Over Voltage | 120%~150% of rated output voltage, hiccup mode | |
Input | 3.15A current fuse | |
Short Circuit | Auto recovery | |
Safety Certifications | UL60950-1, 2nd Edition, 2014 | Certificate Number: E472300 |
CAN/CSA C22.2 No.60950-1-07,2nd Edition, 2014 | Certificate Number: E472300 | |
TUV/GS/CE/LVD EN60950-1, 2006+A11+A1+A12+A2 | Certificate Number: S 50297489 | |
RCM/AS NZS60950.1:2011+A1 | Certificate Number: TUV017488EA | |
PSE/J60950-1(H26) | Certificate Number: JD 50300674 |
Company Information
Certificate
FAQ
Do you have a MOQ requirement? |
| What is the lead time? 3~5 days for testing samples, 2~3 weeks for mass production |
| Can I pay by Paypal for testing samples? Yes |
| What if there are quality problems with the products I bought? We take the following measures to ensure the quality of products |
| 1, Strict management of product design |
| 2, All products on sale are safety certificated |
| 3, Strict production process control |
| 4, Two hours burn-in testing on 100% products |
| 5, Carrying out random finally inspection on each lot |
| There will no defective in large scale. However, as our quality level AQL is: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5, defective is allowed for one or few pieces. We offer 3 year warranty for all items. We provide replacements for all defective products have had at our costs as long as you have picture to prove that these products are broken in the normal use. If you are our regular customer we would include the replacements in the nearest shipment. |
What is the ambient temperature specified for safety test & evaluated by safety testing agencies including UL and TUV? It was 35℃. The data shows on our certifications. |
Our Services
1: Professional service 1) We reply any inquiry in 12 hours Website: www.intaia.com |
2. OEM/ODEM available: 1) Customized products available 2) We can put your ideas into concrete products |
| 3. High quality and reasonable & competitive price |
4. After-Sale Service : We offer 3 years warranty , replacements available |
5. Faster delivery : In term of an urgent order, we apply flexible production management to catch up your delivery date. |
Packaging & Shipping
Each piece in a white box, then 48pcs in an outer carton.
Carton gross weight: 15~22kg, carton size: 53x36.5x21cm
