Full Electric Mini Scissor Lift Platform
- Category: Work Platforms >>>
- Supplier: Qingdao Olift Equipment Co. Ltd.
Share on (1600366779587):
Product Overview
Description
Scissor Access Lifts PM-A series
Advantages:
1.Extended platform provide more workspace.
2.Compact size (1.16m×0.76m×1.8m) provide access in and around confined work areas.
3.Compact design provide access in and around confined work areas.
4. 25% gradeablility when driving on slopes.
5.On-board diagnostice help operators troubleshoot on the fly and make adjustments in the field to maximize uptime.
Standard equipment
1.Proportional controls
2.Self-lock gate on platform
3.Drivable at full height
4.Non marking tyres
5.Automatic brakes
6.Emergency lowering system
7.Emergency stop buttons
Specifications:
Model No. |
| PM1.8A | PM3.0A | PM3.9A | PM4.8A |
Capacity | kg | 300 | 300 | 300 | 300 |
Platform Height(Max) | mm | 1800 | 3000 | 3900 | 4800 |
Platform Height(Min) | mm | 640 | 720 | 800 | 880 |
Platform Size | mm | 1150×600 | 1150×600 | 1150×600 | 1150×600 |
Overall Length | mm | 1160 | 1160 | 1160 | 1160 |
Overall Width | mm | 760 | 760 | 760 | 760 |
Overall Height | mm | 1640 | 1720 | 1800 | 1880 |
Overall Height (Folding) | mm | 1340 | 1420 | 1500 | 1580 |
Ground Clearance (Min) | mm | 60 | 60 | 60 | 60 |
Turning Radius (Min) | mm | 1200 | 1200 | 1200 | 1200 |
Driving Wheels | mm | φ230*80 | φ230*80 | φ230*80 | φ230*80 |
Travel Speed | km/h | 4 | 4 | 4 | 4 |
Battery | V/Ah | 2×12/80 | 2×12/80 | 2×12/80 | 2×12/80 |
Lifting Motor | V/kw | 24/0.8 | 24/0.8 | 24/0.8 | 24/0.8 |
Drive Motors | V/kw | 2×24/0.4 | 2×24/0.4 | 2×24/0.4 | 2×24/0.4 |
Integrated Charger | V/A | 24/15 | 24/15 | 24/15 | 24/15 |
Weight | kg | 600 | 630 | 660 | 690 |
