HFDD-400 Hdd Drilling Machine Horizontal Directional Drilling Rig
- Category: Other Construction Machinery >>>
- Supplier: Zhengzhou,Hanfa,Imp,&,Exp,Trading,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
Horizontal directional drilling machine
Model: HFDD-400
Cummins QSC8.3-C240
Rated power (kW/r/min): 179/2200
Maximum push-pull force (kN): 400
Technical features
1. Hydraulic pilot control, with comfortable operability and flexible adjustment capabilities, overflow brand hydraulic
components to ensure the reliability of the hydraulic system of the whole machine
2. The dual-floating patented technology of power head and vise can greatly protect the thread of the drill pipe and prolong the service life of the drill pipe;
3. The dual-speed control of power head rotation and push-pull can increase the adaptability of the drilling rig's working
conditions and improve the construction efficiency of the drilling rig.
Model: HFDD-400
Cummins QSC8.3-C240
Rated power (kW/r/min): 179/2200
Maximum push-pull force (kN): 400
Technical features
1. Hydraulic pilot control, with comfortable operability and flexible adjustment capabilities, overflow brand hydraulic
components to ensure the reliability of the hydraulic system of the whole machine
2. The dual-floating patented technology of power head and vise can greatly protect the thread of the drill pipe and prolong the service life of the drill pipe;
3. The dual-speed control of power head rotation and push-pull can increase the adaptability of the drilling rig's working
conditions and improve the construction efficiency of the drilling rig.
Technical Data
Engine | Model | Cummins QSC8.3-C240 | |
Rated power | 179/2200 kW/r/min | ||
Push and pull | Maximum pushing force | 400 kN | |
Maximum push-pull speed | 28 m/min | ||
Rotate | torque | 14000 N.m | |
Maximum speed | 104 r/min | ||
Mud pump | Maximum flow | 450 L/min | |
Maximum pressure | 8 MPa | ||
Drill pipe | 83*3mm*m | ||
Truck mounted crane | Lifting weight | / t | |
Lifting moment | / t.m | ||
Max. penetration angle | 23° | ||
Max. back expansion diameter | 900mm | ||
Quality | 11.5t | ||
Overall Dimension | 7080*2450*2450mm | ||
Optical | 1. Double anchoring;2. Mud antifreeze;3. Mud cleaning | ||
Working Principle
Recommend Products
FAQ
1. Are you trading company or manufacturer？
We are professional manufacturer, and our factory mainly produce water well drilling rig, core drilling rig, DTH drilling rig, piling rig, etc. Our products have been exported to more than 50 countries of Asia, South America, Africa, and get a good reputation in the world.
2. Are your products qualified?
Yes, our products all have gained ISO certificate,and we have specialized quality inspection department for checking every machine before leaving our factory.
Yes, our products all have gained ISO certificate,and we have specialized quality inspection department for checking every machine before leaving our factory.
3. How about your machine quality?
All of our machines hold the ISO, QC and TUV certificate, and each set of machine must pass a great number of strict testing in order to offer the best quality to our customers.
All of our machines hold the ISO, QC and TUV certificate, and each set of machine must pass a great number of strict testing in order to offer the best quality to our customers.
4. Do you have after service?
Yes, we have special service team which will offer you professional guidance. If you need, we can send our engineer to your worksite and provide the training for your staff.
Yes, we have special service team which will offer you professional guidance. If you need, we can send our engineer to your worksite and provide the training for your staff.
5. What about the qaulity warranty?
We offer one-year quality warranty for machines' main body.
6. How long can you deliver the machine?
Generally, we can deliver the machine in 7 days.
Generally, we can deliver the machine in 7 days.
