Concrete carbonation test chamber for curing concrete line
- Category: >>>
- Supplier: Wuxi,Harris,Environment,Equipment,Co.,Ltd.
Share on:
Product Overview
Description
Factory direct concrete carbonation test chamber concrete lab equipment
Brands of Main Conponets
| Controller | Conductor Protection Switch | AC contactor | Thermal Relay | Middle Relay | Solid State Relay | Panel Button | Self-reset Fuse |
T&HLS
| Schneider
| SIEMENS
| DELIXI
| OMRON
| Schneider/Taiwan Yangming
| Hongbo (Chinese brand) | Schneider |
Branded Ensure the Quality
Standard features
| Specification | THS-100UA | THS-150UA | THS-250UA | THS-500UA | THS-010UA | |||||
| Workroom Sizes W*D*H (cm) | 50x40x50 | 50x50x60 | 60x60x70 | 80x70x90 | 100x100x100 | |||||
| Inner chamber volume(V) | 100L | 150L | 252L | 504L | 1000L | |||||
| Outer dimension W*D*H(cm) | 98x95x160 | 98x105x170 | 108x112x180 | 128x125x200 | 148x155x210 | |||||
| Packing Size | 113x110x175 | 113x120x185 | 123x127x195 | 133x140x215 | 163x160x225 | |||||
| G.W(kg) | 360 | 390 | 450 | 480 | 620 | |||||
| Temperature Range | A: -20°C-150°C B: -40°C-150°C C: -60°C-150°C D: -70°C-150°C | |||||||||
| Temperature Fluctuation | ≤±0.5°C(standard)/≤±0.2°C(optional) | |||||||||
| Temperature Evenness | ≤±2°C | |||||||||
| Temperature Deviation | ≤1°C | |||||||||
| Accuracy | 0.1°C,1.5%R.H (standard)/0.01℃,1.5%R.H(optional) | |||||||||
| Humidity Range | 20%~98%R.H/ 10%~98%R.H(optional) | |||||||||
| Humidity Deviation | ±2% R.H | |||||||||
| Heating Speed | 1.0°C~3.0°C/min | |||||||||
| Cooling Speed | 0.7°C~1.2°C/min | |||||||||
| Heating time | RT°C~150°C≤30min | |||||||||
| Cooling time | RT°C~-40°C≤60min | |||||||||
| The machine noise | 72 dB(A) | |||||||||
| Load on the largest | 100kg,≤20kg/layer | 150kg,≤26kg/layer | 260kg,≤30kg/layer | 260kg,≤40kg/layer | 300kg,≤60kg/layer | |||||
| Power | ~3.25KW | ~3.55KW | ~3.95KW | ~5.5KW | ~6.25KW | |||||
| material | Inner chamber:# SUS 304 stainless steel | The outer wall:A3 carbon steel plate with plastic spray/#SUS304 | ||||||||
| Wind Cycling Way | Centrifugal fan forced air circulation | |||||||||
| Refrigeration Way | Single stage compression refrigeration | |||||||||
| Refrigerater | French Tecumseh | |||||||||
| Refrigerants | R4O4A USA Dupont environmental protection refrigerant | |||||||||
| Condensing Way | Air-cooled or water-cooled | |||||||||
| Heater | Nickel chrome heating wire heater | |||||||||
| Humidifier | Semi-closed steam and wet | |||||||||
| Water Suplying Way | Automatic cycling water supply | |||||||||
| Controller | Japan OYO/Korea Temi/HLS | |||||||||
| Standard Accessoriesparts | 1 Observe window(double-deck cavity toughened glass),50mm testing hole,PL internal bulbs,partition plate,dry and wet ball gauze,3 fuses,1 power line | |||||||||
| Safety device | Compressor overload protection, fuse protection, Overheat protection,humidifier dry-combustion protection ,high/low pressure of refrigerator ,over-humidity and temperare protection,water shortage protection,over-current protection,Over-current circuit breaker,earth leakage protection | |||||||||
FAQ
Q 1: Are you manufacturer?
A: Yes, we are manufacturer with more than 10 years' experience.
Q 2: What are your Price Terms and depart port?
A : Trade term: FOB, CFR, or CIF, etc. Shipping port: Shanghai normally.
Q 3: What are your Payment Terms?
A: Payment shall be made by T/T, L/C, or D/P, etc., it varies considerably according to the region that you are in.
Q4: What's your Minimum Order Quantity?
A: Any order quantity is warmly welcomed.
Q 5: Do you have English Manual for each machinery?
A: Yes. The instruction manual,the test report and other Data Sheets related shall be provided by us.
Q 6: Can you customize the machine for me ?
A: Yes, we can customize according to customer's requirements.
Q 7: What shall we do if breakdown occurs?
A: Please informed us at once. We shall handle it by the on-line services to make one-one explanation or arrange the personnel to the site see as the requirements.
Q8: Do you support overseas installtion and debugging?
A: Yes, normally we will despatch a profesional team with translater to the field to complete the whole project.
