Product Overview
Description
Product Description
2021 lasted termotanque solar for Argentina market
Low Pressure stailess steel Solar water heater is very popular in many countries and area, such as India, Mexico, Vietnam, China, Chile ,Africa ,south america ,Middle East etc.
A:Features and advantages:
1. High efficient and economical system.
2. Suitable for projects and home use.
3. Designed for commercial solar water heating applications.
4. Reliable and efficient with twin-glass solar tubes.
5. Polyurethane insulation ensures a good heating performance and minimal heat loss.
6. Easy plug-in installation.
7. Can be connected in series to increase water heating capacity.
B.Technical data:
Description | 2021 lasted termotanque solar for Argentina market |
Material of out tank | 0.31-0.4mm thickness Galvanized steel |
Material of inner tank | Food grade 0.31-0.5mm mm thickness SUS304 stainless steel |
Tank insulating layer | 55mm 45kg/m³ high-density polyurethane foamed |
Inlet and outlet hole | Male G 3/4, 3/4 |
Max pressure | 0.05Mpa |
Solar collector tube | 3.3 Borosilicate glass with N/Al coating |
Thickness of glass tube | 1.6mm |
Vacuum tube tightness | P<=0.005 Pa |
Absorption | AS=0.93-0.96(AM1.5) |
Emission ratio | 0.04-0.06(80C+-5C) |
Idle sunning property parameters | Y=220~260m2.C/KW |
Average heat loss coefficient | ULT=0.6~0.7W/(m2.C) |
Bracket: | 1.5mm thickness galvanized steel |
Design of tank: | 4 holes for air vent,water inlet and outlet,Mag Rod |
Welding: | Argon arc welding |
Fastening pieces: | Made of stainless steel screw |
Absorber area | 1.29m² |
Tube quantity | 10 tube 58x1,800mm solar vacuum tube |
Tank capacity | 200L |
Packaging & Shipping
Tank package size: 1800X50X50 cm,frame : 1800x100x270mm,vacuum tube : 10pcs /CTN, 1800x340x170mm
Samples packed in wooden box
Container packed in carton box with PE foam board
