Product Overview
Description
Product Paramenters
Full Servo Pull-Up Baby Diaper Machine
JWC-NK600-EB-SV
1 | Design speed | 800pcs/min |
2 | Working speed | 600-800pcs/min |
3 | Qualified rate | ≥ 97% （exclude the wastage due to the glue applicators and materials splicing joint） |
4 | Efficiency | ≥ 85% |
5 | installation capacity | ≥280KW |
6 | Electricity | 380V ±5%、50HZ |
7 | Wire | Three phases four wires 380V/50Hz (ground wire) 3X120mm³+1X50mm³+1X25mm³ |
8 | Air pressure | ≥0.8Mpa 2.6m³/min |
9 | Total weight | About 78tons |
10 | Machine size | 28.5×8×5 M(L×W×H) |
11 | Working space | 36×12×8 M (L×W×H) |
12 | Machine color | Rice white ,can be changed by order |
13 | Product size | S,M,L,XL |
14 | Containers | 6X40HQ |
FEATURES AT A GLANCE
Human-Machine Interface
Web Guider System
Glue Applicators
1.Machine frame structure and main characters
2. Crusher system
3. Fluff forming system
4. SAP feeding system
5. Bottom tissue feeding, roll diameter φ800mm
6. Upper tissue, roll diameter φ800mm
7. Fluff core wrapped by upper and bottom tissue, also can be wrapped by one whole piece tissue
8. ADL feeding, roll diameter φ800mm
9. Fluff core inner cut device 1 set，adopt frame type structure, increase the cutter life
10. Leak cuff unit
11. Hydrophilic nonwoven supply, roll diameterφ800mm
12. Side tape supply
13. Elastic ear material supply unit
14. Frontal ear material supply
15. Three pieces complex, two sides fixing unit, adhesion pressing
16. Bottom film supply
17. Frontal tape supply
18.Surface layer, absorption core, bottom film pressing
19. One set products cutting unit
20.1set pressing unit(Y shape roller360)
21. Product vertical tri-fold
22. 1 set pressing unit(Y shape roller 200)
23. Transmission unit
24. 1 set final cut unit
25. Horizontal fold transmission unit
26. 2 set horizontal fold unit
27. Product transmission unit
28. Auto rejection exit (pneumatic)
29. Horizontal stacker transmission
Product Configuration
Mitsubishi Servo System
Habasit Conveyor Belts
Optibelts Timing Belts
Similar Products
Elastic Ear Diaper Making Machine
300-600 PIECES PER MINUTE
Pull Up Pants Diaper making machine
300-600 PIECES PER MINUTE
Classic I shape Diapers
300-800 PIECES PER MINUTE
FAQ
Q: Delivery time of whole line
A: Soon delivery. Generally it is 120-150 days
Q: What is your order payment term?
A: 30% deposit in advance and 70% balance before shipment.
Q: Can you present your machine in running?
A: You are warmly welcome to visit our factory; we will show the machine in running on the site.
Q: What is the area needed to set this factory?
A: Considering the workshop and storage, we suggest you 1000-1500SM per production line
Q: Can you send us samples of the finally product?
A: Yes, free samples can be sent out, but the freight charge is paid by you.
But, usually, we design the machine according to the customers’ samples and requirements. We have a professional team with rich experience in machine's appearance design and manufacturing.
Q: Could you also supply raw materials?
A: Yes, surely we can. We have long term cooperation with many raw materials suppliers. They can provide us good quality and good price. This is in our service chain.
Q: How can I know the product cost?
A:
1) We can suggest which kind of product construction is suitable for your market, and analyze the cost of a sample from your local market.
2) We will offer you the cost report in detail according to your sample, so you can now how to calculate the profit in for open factory.
3) We also can give you normal finishing product cost for reference.
Q: what kind of training you can offer?
A:
1) You can send technical to our factory for training how to run the machine before the delivery the machine. You are offered full accommodation by our company.
2) When the machine arrives to your factory, we will send engineer to your place to install and test the machine and also train your workers
3) If you need an engineer work for you more long time, we can help you to hire an experienced staff.
Q: How about the machine guarantee?
A: Soon delivery. Generally it is 120-150 days
Q: What is your order payment term?
A: 30% deposit in advance and 70% balance before shipment.
Q: Can you present your machine in running?
A: You are warmly welcome to visit our factory; we will show the machine in running on the site.
Q: What is the area needed to set this factory?
A: Considering the workshop and storage, we suggest you 1000-1500SM per production line
Q: Can you send us samples of the finally product?
A: Yes, free samples can be sent out, but the freight charge is paid by you.
But, usually, we design the machine according to the customers’ samples and requirements. We have a professional team with rich experience in machine's appearance design and manufacturing.
Q: Could you also supply raw materials?
A: Yes, surely we can. We have long term cooperation with many raw materials suppliers. They can provide us good quality and good price. This is in our service chain.
Q: How can I know the product cost?
A:
1) We can suggest which kind of product construction is suitable for your market, and analyze the cost of a sample from your local market.
2) We will offer you the cost report in detail according to your sample, so you can now how to calculate the profit in for open factory.
3) We also can give you normal finishing product cost for reference.
Q: what kind of training you can offer?
A:
1) You can send technical to our factory for training how to run the machine before the delivery the machine. You are offered full accommodation by our company.
2) When the machine arrives to your factory, we will send engineer to your place to install and test the machine and also train your workers
3) If you need an engineer work for you more long time, we can help you to hire an experienced staff.
Q: How about the machine guarantee?
A: The Seller offers a 12-month quality guarantee period from the delivery date.
