GDE 32A 1P 14 6 Pdu 0u; 200 240v Ac,32a,C13{14} c19{6} Basic Series Power Distribution Units Server Rack Pdu
GDE-32A-1P-14+6 Pdu 0u; 200-240v Ac,32a,C13{14}+c19{6} Basic Series Power Distribution Units Server Rack Pdu
GDE-32A-1P-14+6 Pdu 0u; 200-240v Ac,32a,C13{14}+c19{6} Basic Series Power Distribution Units Server Rack Pdu
GDE-32A-1P-14+6 Pdu 0u; 200-240v Ac,32a,C13{14}+c19{6} Basic Series Power Distribution Units Server Rack Pdu
GDE-32A-1P-14+6 Pdu 0u; 200-240v Ac,32a,C13{14}+c19{6} Basic Series Power Distribution Units Server Rack Pdu
GDE-32A-1P-14+6 Pdu 0u; 200-240v Ac,32a,C13{14}+c19{6} Basic Series Power Distribution Units Server Rack Pdu
GDE-32A-1P-14+6 Pdu 0u; 200-240v Ac,32a,C13{14}+c19{6} Basic Series Power Distribution Units Server Rack Pdu

GDE 32A 1P 14 6 Pdu 0u; 200 240v Ac,32a,C13{14} c19{6} Basic Series Power Distribution Units Server Rack Pdu

Share on (1600374334397):


Price:$74.00 - $77.00

Quantity:


Product Overview

Description





Certifications






Details Images


Socket standard and number
14 way C13+6 way C19 anti-drop
Socket combination
14+6
Internal connection line
 Copper bar connection (diameter 2.5mm)
Power supply input mode
 Junction box (transparent cover)
Cable plug standard
/ customizable
Input terminal connection wire capacity
 3*6mm²
Cable installation method
Upper input
Cable fixing
PG19
Shell color
A road (brown, YR05), B road (peacock blue, PB11)
Dimensions (L*W*H) 1784×60×45mm
1784×60×45mm    Deviation: (L) ±4mm, (W/H) ± 2mm
Fixed hole center distance
1744mm
Aluminum alloy shell length
1684mm
Installation method
bracket installation
Bracket installation direction
Vertical installation
Control indicator function
Hot plug indicator
Protection and monitoring function
Intelligent instrument, monitoring unit
The above content all accept the corresponding customized service


Screw specifications
Required torque ±10%
M3
0.6N.m
6kgf.cm
M4
1.6N.m
16.3kgf.cm
M5
3N.m
30.5kgf.cm
M6
5N.m
51kgf.cm
M8
11N.m
112kgf.cm




Company Profile




VR


Shaoguan Guard Mine Protection Technology Co., Ltd., formerly a national high-tech enterprise Shenzhen Guard(ZB) Technology Co.,Ltd., moved to Industrial transferpark,Lechang , Shaoguan City in 2015. with a registered capital of 70 million yuan, is a manufacturer of surge protectors, PDU sockets,telecom power supply and other related products integrating R&D, production and sales.

●The company has advanced production equipment and management concepts, and has cooperated with dozens of well-known domestic and foreign companies and the world’s top 500 multinational companies, such as: ZTE, Vertiv, Sunsea Communications, SDG, Nanjing Putian, Nanjing Huamai, Kexin, Delta, etc.

●The company has established a high-quality R&D team, including a number of invention patents and utility model patents. The surge protector produced is at the forefront of technology in the country and even the world.

●The company launched the "Guard" brand of surge protectors with complete intellectual property rights and the "Shenhao" brand of high-end lightning protection sockets in 2009 and 2015 respectively.

●The company is located in the Industrial Transfer Industrial Park of Lechang City, Shaoguan City. It will build 12,000 square meters of factory buildings, office buildings and dormitories. It was put into operation in March 2017. The second phase will be completed in 2021.


Product packaging




FAQ


1.How long does it take to get your quotation and detailed information?
Within 24 hours.

2.What about the sample policy?
We provide samples .Please contact us

3.How about delivery time?
Samples cost 8-12 days.Bulk order cost 15-26 days.
