factory PCB Custom launcher supported android digital tv set top box

Item

Description

Packing

Product size

105x105x 20mm

Packaged weight

0.45kg

Loading for 20HQ

435 x305x 300mm

Product Color

Black

System Config

CPU

RK3328    Quadcore  cortex-A53       frequency :1.5G

GPU

 Mali-450MP2

FLASH

16GB/32GB

SDRAM

 1G/2G/4GB

Power Supply

Power Supply

DC 5V/2A

Main Features

Case

Plastic material  (Private model )

OS

Android

KODI

18.0

WIFI

2.4G  +  5G

3D

Hardward 3D graphics acceleration

Support Decoder format

VP9-10 Profile-2 up to 4Kx2K 30fps

H.265 HEVC MP-10  L5.1 up to 4Kx2K 30fps

H.264 AVC HP L5.1 up to 4Kx2K 30fps

H.264 MVC up to 1080P  30fps

MPEG-4 ASP  L5 up to 1080P 60fps (ISO-14496)

WMV/VC-1 SP/MP/AP up to 1080P 60fps

AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps

MPEG-2 MP/HL up to 1080P@ 60fps (ISO-13818)

MPEG-1 MP/HL up to 1080P@ 60fps (ISO-11172)

RealVideo 8/9/10 up to 1080P@ 60fps

WebM up to VGA

Multiple language and multiple format sub-title video support

MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918)

Supports JPEG thumbnail, scaling, rotation and transition effects

Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso, *.mp4, *.rm and *.jpg file

HD MPEG1/2/4,H.264, HD AVC/VC-1,RM/RMVB,Xvid/DivX3/4/5/6 ,RealVideo8/9/10

Support Media format

Avi/Rm/Rmvb/Ts/Vob/Mkv/Mov/ISO/wmv/asf/flv/dat/mpg/mpeg

Support Music format

MP3/WMA/AAC/WAV/OGG/AC3/DDP/TrueHD/DTS/DTS/HD/FLAC/APE

Support Photo format

HD JPEG/BMP/GIF/PNG/TIFF

USB host

1 High speed USB 3.0 and 2 High speed USB 2.0

Card reader

SD/SDHC/MMC cards

HDD file system

FAT16/FAT32/NTFS

Support Subtitle

SRT/SMI/SUB/SSA/IDX+USB

High Difinition video output

SD/HD max.1920x1080 pixel

OSD type of languages

English/French/German/Spanish/Italian/ etc multilateral languages

LAN

Ethernet:Standard 10/100M  RJ-45

Wireless

Built in Dual-band WiFi

Mouse/ Keyboard

Support mouse and keyboard via USB;Support 2.4GHz wireless mouse and keyboard via 2.4GHz USB dongle

HDMI

HDMI 2.0 up to 4k2k Output with HDR, CEC and HDCP 2,2, 4Kx2K@ 60 max

resolution output

4K2k hd decoding

4k2k H.265 Hardware Video Decode and 4k2k Output

1080P/AV/3G

Support

Dolby

Support

SPDIF/IEC958

Coaxial

Software Specifications

Network Function

Skype chatting,Picasa,Youtube,Flicker,Facebook,Online movies,etc

Other feature

Free Internet searching,thousands of android applications,many kinds of games,etc.
