Product Overview
Description
Hot wholesale rotary drum filter screen separator
| parameter | RDS06/400 | RDS06/700 | RDS06/1000 | RDS06/1300 | RDS06/1600 | RDS06/2000 | RDS08/200 | RDS08/2500 |
| Model | ||||||||
| Drum size (mm) | Φ610×400 | Φ610×700 | Φ610×1000 | Φ610×1300 | Φ610×1600 | Φ610×2000 | Φ800×2000 | Φ800×2500 |
| Motor power (kw) | 0.37 | 0.55 | 0.75 | 1.1 | ||||
| Drum speed(rpm) | 4~20 | 2.5~15 | ||||||
| L (mm) | 990 | 1390 | 1690 | 1990 | 2290 | 2590 | 2670 | 3120 |
| W (mm) | 1520 | 1730 | 1750 | |||||
| H (mm) | 1650 | 1930 | 1930 | |||||
| H1 mm (distance from outpipe to ground) | 500 | 600 | ||||||
| Inlet (mm) | DN100 | DN150 | DN150 | DN200 | DN200 | DN200 | DN200 | DN200 |
| Outlet (mm) | DN125 | DN200 | DN200 | DN250 | DN250 | DN250 | DN250×2 | DN300×2 |
| Escape (mm) | DN50 | |||||||
| Sludge discharge(mm) | DN125 | DN150 | DN150×2 | |||||
