Specification | |||||||
Infusion mode | Multiple infusion modes | ||||||
Infusion rate | 0.1--1800ml/h | ||||||
Infusion accuracy | ±2% (After syringe correct calibration) | ||||||
Applicable Syringe | Various brands of sterile syringes: 2ml, 5ml,10ml, 20ml, 30ml, 50ml/60ml | ||||||
Volume to be infused | 0-9999.9(ml) | ||||||
Volume infused | 0-9999.9(ml) | ||||||
KVO rate | 0.1-5 ml/h adjustable; default value 0.1ml/h | ||||||
Bolus rate | 0.1-1800ml/h | ||||||
History record | More than 2000 | ||||||
Alarm | Syringe disengaged, Almost done, Infusion completion, Empty, Occlusion, Low battery, handle off, AC fail, On Battery, Battery exhausted etc. | ||||||
Power supply | DC:12±1.2V AC:100~240V, 50/60HZ | ||||||
Battery | Rechargeable Li_Polymer battery, | ||||||
Battery charging time | 10 hours with power on,3 hours with power off. | ||||||
Power consumption | 35VA | ||||||
Classification | Class I, type CF | ||||||
Waterproof | IP24 | ||||||
Dimension | 230x137x139 mm (LxWxH) | ||||||
Weight | 1.7Kg |
