Double Decker Parking Car Lift Elevator
- Category: >>>
- Supplier: Qingdao Eterlift Machinery Co. Ltd.
Share on (1600384953151):
Product Overview
Description
Related Products
| model | HW1000D | HW2000D | HW4000D | |
| loading | Kg | 1000 | 2000 | 4000 |
| platform size | mm | 1300*820 | 1300*850 | 1700*1200 |
| Base size | mm | 1240*640 | 1220*785 | 1600*900 |
| min/max height | mm | 305/1780 | 360/1780 | 400/2050 |
| lifting time | s | 35-45 | 35/45 | 55-65 |
| power | 380V/50HZ | 380V/50HZ | 380V/50HZ | |
| weight | Kg | 210 | 295 | 520 |
| model | HW500L | HW502L | HW503L | HW2000DL | HW4000DL | HW8000DL | |
| loading | Kg | 500 | 500 | 500 | 2000 | 4000 | 8000 |
| platform size | mm | 2000*800 | 1300*600 | 1300*800 | 2500*820 | 2500*850 | 3400*1200 |
| Base size | mm | 1615*680 | 1210*585 | 1210*585 | 2460*640 | 2450*785 | 2500*900 |
| min/max height | mm | 200/1000 | 180/1000 | 180/1000 | 205/1000 | 230/1000 | 300/1050 |
| lifting time | s | 16-26 | 10-15 | 10-15 | 26-36 | 36-46 | 36-46 |
| power | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | |
| weight | Kg | 193 | 121 | 131 | 265 | 360 | 560 |
| model | HW1000T | HW2000T | |
| loading | Kg | 1000 | 2000 |
| platform size | mm | 1700*1000 | 1700*1000 |
| Base size | mm | 1600*1000 | 1060*1010 |
| min/max height | mm | 470/3000 | 560/3000 |
| lifting time | s | 35-45 | 50-60 |
| power | 380V/50HZ,AC2.2kw | ||
| weight | Kg | 450 | 750 |
