15000 x 5500 x 5000 mm (L x W x H)
16300 x 5650 x 5400 mm (L x W x H)
About 3500 x 5650 x 5400 mm (L x W x H)
The house is mainly composed of a wind cabinet, a skeleton and a PVC soft curtain.
(The color of PVC curtain is basically complete, specifically white, gray, yellow, and transparent. Please confirm when ordering.)
Access filter door
There is a filter in and out of the front door of the house. The door size is 4000X4500mm, and
the high-efficiency air filter cotton is installed on the door.
Service door is installed on the door, service door size is 800*1900mm, and tempered glass
perspective window is installed.
24 groups, 20W/group, LED explosion-proof lamp
34 groups, 20W/group, LED explosion-proof lamp
V paper filter and paint-stop filter
The exhaust is equipped with two 4KW aluminum alloy vane axial flow fans (external motor),
Air Flow Speed
0.45 m/s in empty booth,
Standard 2 Ø800X3000mm round tubes, 2 elbows
Standard control system
Fan start, lighting, frequency conversion adjustment, fault alarm, emergency stop switch
