Wholesale Price Pneumatic 4v 4v110 4v210 4v410 4v310 Air Valve Solenoid Valve
Wholesale Price Pneumatic 4v 4v110 4v210 4v410 4v310 Air Valve Solenoid Valve
Wholesale Price Pneumatic 4v 4v110 4v210 4v410 4v310 Air Valve Solenoid Valve
Wholesale Price Pneumatic 4v 4v110 4v210 4v410 4v310 Air Valve Solenoid Valve
Wholesale Price Pneumatic 4v 4v110 4v210 4v410 4v310 Air Valve Solenoid Valve
Wholesale Price Pneumatic 4v 4v110 4v210 4v410 4v310 Air Valve Solenoid Valve
Wholesale Price Pneumatic 4v 4v110 4v210 4v410 4v310 Air Valve Solenoid Valve

Wholesale Price Pneumatic 4v 4v110 4v210 4v410 4v310 Air Valve Solenoid Valve

Share on (1600397203403):


Price:$3.50 - $5.95

Quantity:


Product Overview

Description





Products Description


Model
4V110-M5
4V120-M5
4V130C-M5
4V130E-M5
4V130P-M5
4V110-06
4V120-06
4V130C-06
Working Media
Air
Action Mode
Internal Pilot Type
Position
5/2Post
5/3Port
5/2Port
5/3Port
Effective Sectional Area
5.5mm^2(Cv=0.31)
5mm^2(Cv=0.28)
12.0mm^2(Cv=0.67)
9.0mm^2(Cv=0.50)
Port Size
Input=Output=Exhaust Port=M5*0.8
Input=Output=Exhaust Port=G1/8
Lubrication
No Need
Working Pressire
0.15~0.8Mpa
Proof Pressure
1.0Mpa
Working Temperature
0~60℃
Voltage Range
±10%
Power Consumption
AC:2.8VA DC:2.8W
Insulation Grade
F Level
Protection Class
IP65(DIN40050)
Connecting Type
Wiring Type/Plug Type
Max.Operating Frequency
5Cycle/Sec
3Cycle/Sec
5Cycle/Sec
3Cycle/Sec
Min.Excitation Time
0.05Sec
Material
Body
Aluminum Alloy
Seal
NBR


Model
A
B
C
D
E
F
4V110-M5
M5
0
27
14.7
13.6
0
4V110-06
G1/8
2
28
14.2
16
3
4V120-M5
M5
0
27
57
13.6
0
4V120-06
G1/8
2
28
56.5
16
3
4V130-M5
M5
0
27
57
13.6
0
4V130-06
G1/8
2
28
56.5
16
3
