UL listed G GC Shd Gc 2kv Flexible Rubber trailing cable 5KV 8kv Epr Rubber Insulated Power Cable

Share on:


Price:$0.45 - $1.00
Price in USD:Details

Quantity:


Product Overview

Description


TOP TEN CABLE MANUFACTURER/EXPORTER IN CHINA
LARGEST CABLE MANUFACTUER IN NORTH CHINA
ANNUAL EXPORT VOLUME EXCEED 200MILLION USD
WITH UL,TUV,KEMA,CE,BV,PSB,SABS,LLOYD'S,GL,NK,KR,ABS PRODUCTS CERTIFICATIONS
WITH TUV TYPE TESTING REPORT
WIDE PRODUCTS RANGE

ISO9001,ISO18001,OHSAS18001 SYSTEM CERTIFICATIONS
CNAS APPROVAL LABROTARY






OUR Advantages


1. 22 years production experience and 13 years export experience. with good quality and competitive price.
2 Annual Export amount more than 400million USD. Yearly manufacturing capacity 3 Billion RMB.
3 .Main products: Rubber Cables(upto 35kV),Mining Cable,1-35kV PVC &XLPE(LV&MV)Power Cables , Elevator Cable,Reeling/Trailing Cables,ESP cable, Solar PV Cables,Bare Conductor (AAC,ACSR,AAAC), ABC cables,Electric Wires, Control Cables, Welding Cable,Screened Cables and so on.
4.Products certification:UL,CE,BV,TUV,KEMA,PSB,SABS,ABS,NK,LR,KR,GL,DNV;
5. OEM/ODM service available, help you on designing.
6. Cable solutions to your particular requirements
7. Strict quality control system.
8. Strong technical support (technical data, drawing, etc.)
10. Free sample is available with economic express fee.


Please contact us directlyJACK NAMECARD



UL and MSHA certificate Type SHD-GC 8kV EPDM Insulated CR sheathed mining cable





1 APPLICATIONS
Type W G GC Portable Power Cable is suitable for use in Industrial and light-to-medium mining applications, heavy-duty service and temporary as power supply cables. Motor, battery and generator leads. It is also used for mobile and portable electrical equipment.





2 SPECIFICATIONS


• UL Listed - Type W per UL 1650


• Conductors are manufactured in accordance with ASTM and B-172
• Made in accordance with ICEA S-75-381
• NEMA WC-58 - Portable and Power Feeder Cables for Use in Mines and Similar Locations
• MSHA accepted, P-136-135, LR65300
• UL Listed as Type RHH or RHW-2
• or c(UL) Certified as applicable
• RoHS Compliant
• Meets FT-5 Flame Test





3 CONSTRUCTION


   Conductor: 8 AWG to 500 MCM fully annealed stranded bare copper Stranding per ASTM B 174


   INSULATION: Premium grade oil resistant Ethylene Propylene (EPDM)


  JACKET:Premium grade, water, sunlight, and oil resistant, flame-retardant, Chlorinated Polyethylene (CPE)





4 Data sheet of Type W cable:


type W cable.png





mining-cable29mining-cable-31mining






Certifications


We are one of China top rank cable&wire manufacturer.Our products meet standards of GB, IEC DIN ASTM, JIS, NF, AS/NZS  GOST and so on. At thte same time, we have obtained ISO9001,ISO14001,OHSAS18001, UL,CE,KEMA, TUV, Bureau Veritas, Lloyd,IEC,GL,SA,NK,KR certificate





USA is our main market. We have many distributors from USA companies. And we have obtained UL certifications for many products, such as TC cable, DLO cable,RHH/RHW/RHW-2/XHH/XHHW/XHHW-2/SIS, THHN/THHW/THW/THW-2/THWN/THWN-2/TW,SER/SEU/USE/USE-2/MHF, MV-90/MV-105,TC cable,MC cable,DLO,type DG,PV wire,AC Cable,Soow,Welding cable  and so on.


UL certificate.jpg














Packaging & Shipping


Standard export drum,500meters/rdum,1000meters/drum or as your requirment.


888888





Company Information


 Established in 1993, Hebei Huatong Wires and Cables Group Co., Ltd covers an area more than 220,000 square meters, owning more than 420 sets manufacturing equipment and more than 250 sets of testing equipment or apparatus. Our annual production capacity is 3 billionYuan.Now there are more than 800 employers in our company, among which more than 150 are technicians. With the continuous efforts from all the employers, Hebei Huatong Wires and Cables Group Co., Ltd has realized great development to become a modern enterprise and one of the comprehensive, largescale enterprises in domestic wire and cable industry. Our products are widely used in the field of electric power, coal, metallurgy, petrochemical industry, railway, national defense, construction, aviation and other national key projects. Our products have extensive influence and good reputation in both domestic and worldwide market, such as the United States, Holland, Italy, Russia, Britain, Australia, New Zealand, Ethiopia, Ghana, Algeria,Congo, Middle East and Southeast Asia and so on.


office





laboratory


Our laboratory center are authorized by both of ILAC (International Laboratory Accreditation Cooperation)&CNAS(China National Accreditation Service for Conformity Assessment), so the testing results in our labs can be accepted by the international countries belong to the above organizations.


initpintu_initpintu_initp





FAQ


1.How many year have our factory producing power cable?


Our factory produce power cable for 22 years.


2 Hong Long time the customer can get the new price after get your inquiry?


 Usually , It is only one hour is ok for us , because we are factory , we caate the price by ourself.


3.Which port our factory is near to?   Tianjin port


4.Which payment term do we accept?


 T/T 30% in advance and balance before shiping the product or L/C 100% at sight both is ok.


5.What about the package for our power cable?


 It is usually packed in strong wooden drum.The drum size is usually:2.0m x 1.25m x 1.12m x 1.4m which suitable for container , we can do it according to customer requirments.


6.How long meter power cable for one wooden drum?


  This is according to power cable's diameter and customer's requirments.


7.How about our delivery time?


  According to your order's quantity , for 1million meters power cable, it is only 25 working days is ok.


8.Do we provide sample for free?


  Yes , we provide the sample to you for free , you only paid for the delivery freight is ok.
