Product Description
Electrical connection ratings
Connection cross-section |
0.14 ... 1 mm² |
Rated impulse withstand voltage Uimp |
2.5 kV |
Rated insulation voltage Ui |
250 V |
Short circuit protection according to IEC 60269-1 |
6A gG |
Switching current |
|
min. at DC 24V |
10 mA |
thermal rated current Ith |
6 A |
Utilization category |
|
AC-15 |
2A 230V |
DC-13 |
2A 24V |
Mechanical values and environment
Actuating element |
|
Steel ball D ball = 4mm |
Ball plunger |
Actuating force |
15 ... 20 N |
Ambient temperature |
-5 ... +80 °C |
Approach speed |
0.01 ... 8 m/min |
Connection |
|
1 x |
M12 x 1.5 |
Degree of protection |
IP67 |
Installation orientation |
any |
Material |
|
Contact |
Silver alloy, gold flashed |
Housing |
Anodized die-cast alloy |
Number of door position NC contacts |
1 |
Number of door position NO contacts |
1 |
Switching principle |
Changeover contact with snap-action function |
Tightening torque |
|
Switching element screw terminal |
max. 0.2 Nm Hexagon socket AF 1.3 mm |
other types
N1AR502SVM5-M |
N1AD514-M |
NB01K556-M |
N01D550-M |
NB01D556-M |
N01D572-M |
EGT1SEM4C1613 |
