S50V2 long range N3680 2D barcode scanner android explosion proof handheld rug pda
S50V2 long range N3680 2D barcode scanner android explosion-proof handheld rug pda
S50V2 long range N3680 2D barcode scanner android explosion-proof handheld rug pda
S50V2 long range N3680 2D barcode scanner android explosion-proof handheld rug pda
S50V2 long range N3680 2D barcode scanner android explosion-proof handheld rug pda
S50V2 long range N3680 2D barcode scanner android explosion-proof handheld rug pda
S50V2 long range N3680 2D barcode scanner android explosion-proof handheld rug pda
S50V2 long range N3680 2D barcode scanner android explosion-proof handheld rug pda
S50V2 long range N3680 2D barcode scanner android explosion-proof handheld rug pda

S50V2 long range N3680 2D barcode scanner android explosion proof handheld rug pda

Share on:


Price:$255.00 - $265.00
Price in USD:Details

Quantity:


Product Overview

Description











1：Power button
2：Scan button
3：MIC
4：Front camera
5：earphone
6：light sensation
7：Handset
8：charge lamp
9：Home
10：Arrow keys and confirm key
11：Menu key
12：Back key
13：Number key
14：Power ON/OFF
15：* Button
16：# Button
17：ChargePoint
18：USB
19：Volume up
20：Volume Down
21：main camera （optional)
22：Function box(optional)
23：Speaker
24：battery














Hardware
CPU
ARM A53 1.5GHz Qude -core
GPU
Mali-T720
RAM
3G
Internal Memory
32G
External Memory
Micro SD card ( T-FLASH card), max 128GB
Main Camera
13.0MP(AF) with flash led
Sub Camera
N/A
Battery
5000mAh（Replaceable battery）
Display
4.5 inch IPS/AFFS 960*540 QHD industrial 500nit Sunlight Readable
Touch Panel
Capacitive/frosted tempered film supports glove touch/spray/active capacitive pen


IO/Sensor/Navigation
SIM Card
1.8/3.3V SIM card
TF Card
Micro SD card ( T-FLASH card) ;max 128GB
Headphone
3.5mm (CTIA）
Data interface
USB Mini 5pin support OTG
Direction Sensor
Support
Gravity sensor
Support
Magnetic Field Sensor
Support
Motion sensor
Support
Rotation Vector
Support
Light-sensor
Support
Acceleration sensor
Support
Charger
5.0V 2A-10W
Navigation
GPS+Beidou+AGPS（EPO）optional（GPS+Glonass)


Appearance
Size
197*92*26.5mm（L×W×H）
Weight
420g
Color & Material
Black&yellow Black&green Black&Gray


Communications & Networking
Phone Call
GSM /WCDMA//VoLTE
2G
GSM/CDMA 1X/EDGE/GPRS/WAP
2G Band
GSM（B2/3/5/8）
3G
WCDMA 3.75G (HSDPA+ 42.2Mbps, HSUPA+ 11.5Mbps)
3G Band
WCDMA（B1/2/5/8）
4G
FDD: 150Mbps down, 50Mbps UP TDD: 150Mbps downlink , 50Mbps uplink
4G Band
TD-LTE（B38/39/40/41）；FDD LTE（B1/2/3/5/7/20）
WI-FI
Dual-band (2.4GHz/5Ghz) single stream 802.11 a/b/g/n/ac
Bt
4.0 Low Energy (LE)


Industrial & Reliability Design
Shake-proof
1-19Hz/1.0mm; 19-200Hz/1.0g
Dropproof /IK
MIL-STD-810G/Method516.6/Procedure IV & Touch Panel IK05
Waterproof
Class 5 ( IEC 60529 )
Dustproof
Class 6 ( IEC 60529 )
Reliability
MTBF>5000h；MTTR
Operating
-20°C to 55°C
Storage Temperature
-40°C to 80°C
RH
5% to 95%
Operating Altitude
Max: 4,500 m（15,000 feet）


Certification/OS/Software
Certification
MA /3C /FCC/CE/ROHS/ATEX/IP67（IEC 60529）
Language
English, Spanish, Portuguese (Brazil), Portuguese (Portugal), Italian, German, Dutch, French, Polish, Romanian, Turkish, Russian,
Arabic, Indonesian, Malay, Thai, Vietnamese, Hindi, Hebrew, Simplified， Chinese,Chinese Traditional,etc
OS
Andriod 5.1/7.0


Package/Warranty terms/OEM
Warranty
24 months
OEM/ODM
Support
Package
USB cable/Charger 5V 2A/Introduction manual/Screen protector/Packing box（Can be customized logo）/Aircraft box/Toolkit（optional）










Q :Are you manufacturer?
A: Yes, we are manufacturers.We can provide OEM / ODM customized service according to our customers’ various application and demands.All of our products are fully patented, ID/MD design, hardware and software,mold,assembly are done by our own team.

Q: Would you provide SDK for me?
A: Yes, we offer free SDK if you order sample.In addition, we also have support engineers to assist you with software development.

Q: What is the minimum order(MOQ)?
A: We accept one unit for standard products.we can even customized with your logo if needed. If require OEM, will see detailed requirements and confirm MOQ to you from our sales department.

Q: Can we get the free sample?
A: Sorry, generally we would not provide the free sample. If the customer confirm the specification and price, they can order the sample firstly for the testing and evaluation.

Q: Can i choose multiple function into 1 device?
A: Yes, you can choose multiple fuction into onedevice, Different functions depending on the product model,optional functions:RFID (LF/HF/UHF)1 Fingerprint/ Bar code scanner.

Q: How to order and pay?
A: We accept T/T (bank transfer), Alibaba online,Western Union 1 Trade Assurance

Q: What's Your Products Warranty?
A: We Offer 24 Months Warranty after shipment sent.

Q: Can I extend the warranty?
A: We offer a deferred warranty for up to 36 Months, and the price for the warranty extension is 10% up.

Q: How long it will take for delivery?
A: For production lead time around 3-10days depend on requirement, and shipping time by DHL/UPS/FEDEX/TNT, delivery time would around 3-5 working days. For some remote place, delivery time maybe a little bit longer.

Q:How to repair the device if any problem ?
A: We will provide technical support online to solve problem; If for the hardware problem , we couldsend the parts or components and teach customer to fit if they have technician or can also send backto us to fix it.

Q: Can you do customized and preload our software?
A:We are professional rugged device manufacture with 11 years experiences
