3 um PTFE Cartridge Chemical Industry And Gas Filtration Strong Hydrophobicity Millipore filter
- Category: >>>
- Supplier: Shantou Yalida Filtration Equipment Co. Ltd.
Share on (1600404467166):
Product Overview
Description
3 um PTFE Cartridge Chemical Industry And Gas Filtration Strong Hydrophobicity
Product Description
Specifications and technical parameters
| Filter medium | PTFE Hydrophobic Microporous Filter |
| Support layer | Polypropylene (PP) |
| Filter cage | Polypropylene (PP) |
| Pore size | 0.05,0.1,0.2,0.45,1µm |
| Length | 10 inches |
| OD/ID | 69 mm-34 mm |
| Gasket / O - rings | Silicone, NBR, EPDM, Viton |
| Interface | DOE,215,222,226flat/fins |
| End caps | DOE,0050,0050A,0050B |
| Sealing method | thermal bonding technique |
| Effective filtration area | 0.6 m2/10" |
| Max. operating temperature | 140℃, 0.27 Mpa |
| Max. forwarder differential pressure | 0.42 Mpa (25℃) |
| Max. reverse differential pressure | 0.28 Mpa (25℃) |
| Sterilizing temperature | 121℃ 30min |
Applications
,
- Medical industry: sterile filtration of raw material pharmacy, medical liquid degerming
- Food industry: wine, beverage, grape, liquor
- Chemical industry: filtration for organic solvent, various alcohols, chemical reagent
Company Information
Shantou Yalida Filtration Equipment Co.,Ltd. was established in 2005, which specialized in Water, liquid
and air filtration equipment manufacturer.Our company has introduced the advanced production equipments,
quality control instruments and manufacture technology for micropore filter cartridge since it was found.
