Product Overview

Description



Raw Material
Density
Hardness
Co Content
Grain Size
Bending strengh
YG10X
14.5
91.5
10
1.0
≥2800
ZK30UF
14.3～14.6
92.0
10
0.6
≥3000
GU25UF
14.3～14.6
93
12
0.4
≥4000




HRC45 deg Tungsten Steel 2 Flute Ball Nose End Mills

Raw Material:Use Zigong YG10X,high hardness,good wear resistance and corrosion resistance.



Tolerance of End Mill Diameter:



1＜D≤6       -0.010～-0.030



6＜D≤10      -0.015～-0.040



10＜D≤20     -0.020～-0.050



Cutting Parameters:



Vc =130（120-180）m/min



ap=1/3D(1/8-1/2D)



ae=1/2D(1/4-1D)



fz=0.15mm(0.02-0.2)



Please adjust the parameters according to the material and hardness of workpiece.



Coating:AlTiN,high aluminum content provides excellent hot hardness and oxidation resistance.



Double-edge design improves rigidity and surface finish effectively.Cutting edge over the center reduces the cutting resistance. High capacity of junk slot benefits chip removal and increases machining efficiency. 2flutes design is good for chip removal,easy for vertical feed processing,widely used in slot,profile,and hole processing.



Workpiece Material
Carbon Steel
Alloy Steel
Cast Iron
Aluminum Alloy
Copper Alloy
Stainless Steel
Hardened Steel
Y
Y
Y
