NanoVNA V2 F 50K 3G 4.3 Inch LCD display Vector Network Analyzer HF VHF UHF 50Khz 3000Mhz Antenna Analyzer
- Category: >>>
- Supplier: Shenzhen Linguan Technology Co. Ltd.
Share on (1600412021408):
Product Overview
Description
Specification
item | value |
Warranty | 1 years |
Place of Origin | China |
Guangdong | |
Brand Name | LGKJ |
Model Number | NanoVNA-V2 |
Frequency range | 50kHz-3GHz |
RF output power | -9dBm (error within 1GHz: ±1dB) |
Frequency accuracy | <0.5ppm |
Number of calibration points | 201 points |
Number of scanning points | 201 points |
Number of traces | 4 |
Product Description
Product performance:
Frequency range: 50kHz-3GHz
RF output power: -9dBm (error within 1GHz: ±1dB)
Frequency accuracy: <0.5ppm
S21 dynamic range: 70dB (1.5GHz), 60dB (3GHz)
S11 dynamic range: 50dB (1.5GHz), 40dB (3GHz)
2-port return loss: 20dB typ (1.5GHz), 13dB min (3GHz)
Number of calibration points: 201 points
Number of scanning points: 201 points
Number of traces: 4
Number of mark points: 4 (the mark point bar can be moved up and down on the screen)
USB interface: USB Type-C communication mode: CDC (serial)
Setting save: 5 groups (after saving, it can be directly recalled when it is turned on next time, no need to recalibrate, and the saved parameters before the last shutdown will be automatically recalled when it is turned on next time)
Support calibration result interpolation, can measure without recalibration after adjusting the measurement frequency band Scan time: about 1.9s/1 time (50kHz ~ 3000MHz full frequency band)
Can measure S parameters, voltage standing wave ratio, Smith chart, phase, group delay, etc.
Frequency range: 50kHz-3GHz
RF output power: -9dBm (error within 1GHz: ±1dB)
Frequency accuracy: <0.5ppm
S21 dynamic range: 70dB (1.5GHz), 60dB (3GHz)
S11 dynamic range: 50dB (1.5GHz), 40dB (3GHz)
2-port return loss: 20dB typ (1.5GHz), 13dB min (3GHz)
Number of calibration points: 201 points
Number of scanning points: 201 points
Number of traces: 4
Number of mark points: 4 (the mark point bar can be moved up and down on the screen)
USB interface: USB Type-C communication mode: CDC (serial)
Setting save: 5 groups (after saving, it can be directly recalled when it is turned on next time, no need to recalibrate, and the saved parameters before the last shutdown will be automatically recalled when it is turned on next time)
Support calibration result interpolation, can measure without recalibration after adjusting the measurement frequency band Scan time: about 1.9s/1 time (50kHz ~ 3000MHz full frequency band)
Can measure S parameters, voltage standing wave ratio, Smith chart, phase, group delay, etc.
Product acessories:
Host x1
SMA open calibration kit x1
SMA short-circuit calibration kit x1
SMA 50Ω load calibration kit x1
SMA-KK double head female hole adapter x1
SMA-JJ double-head male pin adapter x1
SMA-JKW elbow outer screw inner hole to inner screw inner needle adapter x1
20cm SMA-JJ RG405 RF cable x2
USB type-C data cable x1
Stylus x1
Host x1
SMA open calibration kit x1
SMA short-circuit calibration kit x1
SMA 50Ω load calibration kit x1
SMA-KK double head female hole adapter x1
SMA-JJ double-head male pin adapter x1
SMA-JKW elbow outer screw inner hole to inner screw inner needle adapter x1
20cm SMA-JJ RG405 RF cable x2
USB type-C data cable x1
Stylus x1
Features:
1. 4.3-inch IPS LCD display, resolution 800*480, ultra-wide viewing angle, long-term use does not hurt your eyes;
2. All-aluminum alloy case, sturdy and durable, effectively shielding electromagnetic interference to ensure measurement accuracy;
3. The body size is 125mm*75mm*20mm, compact and portable;
4. The radio frequency interface is SMA, which is convenient for connecting all kinds of DUTs;
5. 5000mAh large-capacity lithium battery, battery life up to 7 hours;
6. Full touch screen design, with 3 side buttons at the same time, flexible and convenient operation;
7. Support Chinese and English interface;
8. Optimized UI design, convenient for users to perform measurement operations;
9. Support screen brightness adjustment;
10. The firmware can be upgraded through a virtual U disk, no programmer is needed, and the firmware can be upgraded through the USB type-c data cable included with the machine;
11. Standard high-quality calibration parts and RG405 phase-stable cable to ensure calibration accuracy;
12. Designed with USB power output interface, which can support 5V/1A power output;
13. Using 2A high current charging IC, the charging time is shorter;
14. Supporting host computer software, the host computer supports Chinese and English interfaces;
15. The screen image of the device can be obtained by taking a screenshot of the host computer;
1. 4.3-inch IPS LCD display, resolution 800*480, ultra-wide viewing angle, long-term use does not hurt your eyes;
2. All-aluminum alloy case, sturdy and durable, effectively shielding electromagnetic interference to ensure measurement accuracy;
3. The body size is 125mm*75mm*20mm, compact and portable;
4. The radio frequency interface is SMA, which is convenient for connecting all kinds of DUTs;
5. 5000mAh large-capacity lithium battery, battery life up to 7 hours;
6. Full touch screen design, with 3 side buttons at the same time, flexible and convenient operation;
7. Support Chinese and English interface;
8. Optimized UI design, convenient for users to perform measurement operations;
9. Support screen brightness adjustment;
10. The firmware can be upgraded through a virtual U disk, no programmer is needed, and the firmware can be upgraded through the USB type-c data cable included with the machine;
11. Standard high-quality calibration parts and RG405 phase-stable cable to ensure calibration accuracy;
12. Designed with USB power output interface, which can support 5V/1A power output;
13. Using 2A high current charging IC, the charging time is shorter;
14. Supporting host computer software, the host computer supports Chinese and English interfaces;
15. The screen image of the device can be obtained by taking a screenshot of the host computer;
