JXJ 2.0MP AHD Business Locations Or Large Homes Cctv Camera Digital Hd Camera Recording Dvr 8 Channel Digital Video Recorders
- Category: >>>
- Supplier: Shenzhen Jiaxinjie Wisdom Iot Co. Ltd.
Share on (1600412090738):
Product Overview
Description
JXJ 2.0MP AHD Business Locations Or Large Homes Cctv Camera Digital Hd Camera Recording Dvr 8 Channel Digital Video Recorders
Style No. | FA24 | |||
Image Sensor | 1/2.8'' Fullhan 8536H+SOI F37 | |||
Resolution | 1920 (H) × 1080(V) | |||
Effective Pixels | 2MP | |||
Signal System | PAL/NTSC(switched by OSD) | |||
Day-night Mode | External (Default)/Auto/Color/White&Black (switched by OSD) | |||
S/N Ratio | ≥50DB | |||
Minimum illumination | 0.2LUX | |||
BLC | AUTO | |||
(AES)Auto electronic shutter | AUTO/ 1/50(1/60)-1/50,000sec | |||
AWB | AUTO | |||
IR control input voltage | OFF(DC 0V) / ON:DC 3V-8V | |||
OSD language | English/ Simplified Chinese(Only 2 languages are supported now) | |||
Video output | AHD/TVI/CVI/CVBS | |||
Video record occupation | 1min≈35.2MB(3.6mm lens) | |||
Working Voltage | DC12V/82mA ±6mA(Wide voltage 9V-18V) | |||
Working environment | -30℃ --- 85℃ | |||
RECORDER | ||||
Main processor | Hi3520D V200 | |||
Preview | 1/4 | |||
Codec | H.264 | |||
Monitor quality | VGA,HDMI:HD | |||
Preview ability | 4*1080N | |||
Encode ability | 4*1080N | |||
Decode ability | 1*1080N | |||
Multi-mode input | analog: 4*1080N;4*720P;4*960H hybrid: 2*720P(analog)+2*720P(network); network:8*1080P;12*960P;8*720P; 4*1080P; 4*720P; 1*1080P | |||
Motion Detection | Each screen can be set to 192 (16 * 12) detection areas; multi-level sensitivity can be set (Limited local channel) | |||
Audio compression | G.711A | |||
Intercom | Support | |||
Record mode | manual>alarm>motion detection>timing | |||
Local Playback | 4ch(analog input mode) | |||
Search mode | Search by time, calendar, event, channel | |||
Video storage | HDD, network | |||
Backup mode | Network, USB hard disk, USB burner, SATA burner | |||
Video input | 4ch BNC | |||
Video output | 1ch VGA, 1ch HDMI | |||
Loop Vout | N/A | |||
Audio I/O | 1/4 | |||
Alarm I/O | 0(Can be extended to 4ch)/0(Can be extended to 1ch) | |||
Network interface | RJ45 10M/100M self-adaption | |||
PTZ control | 1*RS485, Support kinds of PTZ protocols | |||
USB | 2* USB 2.0 ports | |||
HDD | 2*SATA ports (Max 8TB/per) | |||
Wireless | 3G, WIFI (extend via USB) | |||
Power supply | 12V/4A | |||
Power Consumption | <15W (without HDD) | |||
Working environment | Temperature:0℃—+55℃,Humidity:10%—90%,Atm:86kpa—106kpa | |||
Dimension | 171mm*78mm | |||
Weight | 135g | |||
Shenzhen Jiaxinjie Wisdom IoT Co., Ltd. (referred to as JXJ) is the subsidiary of Jiangxi Jiaxinjie Electronic Co., Ltd., which was founded in 2006. It focuses on the R&D, production, sales and overall solutions for security products, relying on industry-leading core technologies such as audio and video codec, transmission, storage, intelligent analysis and its own strong sustainable R&D capabilities.
JXJ products including analog cameras/HD network cameras, smart dome cameras/HD network smart domes, HD SDI cameras, hard disk SDI recorders, DVR/NVR, video matrix, HD decoding servers, optical transceivers, LCD monitors, LCD splicing walls and integrated video management platform, which are widely used in government project, public security, transportation, finance, communications, energy, education, tourism, communities, medical and other fields.
JXJ has 1,000+ workers and covers an area of more than 100,000+ square meters in Jiangxi and Shenzhen, equipped with advanced SMT assembly lines and test machines. We strives to constantly improve quality control management under the ISO9001-2008 system and follow the 7S management principles. The core products are certified both domestically and internationally such as CE, FCC, CCC, MA, RoHS, etc..
JXJ products including analog cameras/HD network cameras, smart dome cameras/HD network smart domes, HD SDI cameras, hard disk SDI recorders, DVR/NVR, video matrix, HD decoding servers, optical transceivers, LCD monitors, LCD splicing walls and integrated video management platform, which are widely used in government project, public security, transportation, finance, communications, energy, education, tourism, communities, medical and other fields.
JXJ has 1,000+ workers and covers an area of more than 100,000+ square meters in Jiangxi and Shenzhen, equipped with advanced SMT assembly lines and test machines. We strives to constantly improve quality control management under the ISO9001-2008 system and follow the 7S management principles. The core products are certified both domestically and internationally such as CE, FCC, CCC, MA, RoHS, etc..
1. Who are we?
JXJ Group was founded in 2006 and has been specilaized in security products for more than 15 years. We have been highly recognized by society and industries, decorated with awards from all areas such as,
AAAA Good Standardized Practice Certificate,
China Security Product Quality Trustworthy Enterprise,
Guangdong Excellent Security Enterprise, China Security Industry Top 100 Enterprise,
Vice President Unit of Shenzhen Security Industry Association.
Our own brand have continuously won the top 10 National Brands in the Security Industry,
10 Innovative Brands in the Security Industry,
The Recommended Brand for Safe City Construction,
The Excellent Security Products Recommended for Safe City Construction,
The Excellent Security Products Recommended for Safe City Construction,
The Top 10 Cutting-edge Security Products in China, and the China Security Expo Golden Tripod Award.
2.What is our proudcts?
Analog cameras/HD network cameras, smart dome cameras/HD network smart domes, HD SDI cameras, hard disk SDI recorders, DVR/NVR, video matrix, HD decoding servers, optical transceivers, LCD monitors, LCD splicing walls and integrated video management platform.
3.Where is our factory?
We moved our production base to Jiangxi Province in 2020. It covers an area more than 100,000 square meters, equipped with advanced machines and production lines.
2.What is our proudcts?
Analog cameras/HD network cameras, smart dome cameras/HD network smart domes, HD SDI cameras, hard disk SDI recorders, DVR/NVR, video matrix, HD decoding servers, optical transceivers, LCD monitors, LCD splicing walls and integrated video management platform.
3.Where is our factory?
We moved our production base to Jiangxi Province in 2020. It covers an area more than 100,000 square meters, equipped with advanced machines and production lines.
4. What services can we provide?
Accepted Delivery Terms: EXW, FOB, CIF
Accepted Payment Currency: USD, EUR, CNY
Accepted Payment Type: T/T, MoneyGram, Credit Card, PayPal, Western Union
Language Spoken: English, Chinese
5.Who have we been cooperated with?
We have been working with many leading international companies as below.
Accepted Delivery Terms: EXW, FOB, CIF
Accepted Payment Currency: USD, EUR, CNY
Accepted Payment Type: T/T, MoneyGram, Credit Card, PayPal, Western Union
Language Spoken: English, Chinese
5.Who have we been cooperated with?
We have been working with many leading international companies as below.
