Origin Eiw Enameled Cca Winding Wire Copper Manufacturer Factory Directly China Solid Braided Silicone Copper Clad Aluminum Wire

Factory Directly china origin eiw enameled cca winding wire manufacturer

Enameled CCA wire is a new electromagnetic wire taking copper clad aluminum as inner conductor material, with characteristics between copper and aluminum. It combines excellent conductivity of copper and light weight of aluminum.
Standard:
SJ/T11223-2000 Copper Clad Aluminum Wire GB/T6109.1 ~ 11-2008 Enameled Round Winding Wire

Advantage
1. DC resistivity
The DC resistivity of CCA wire is approximately 1.45 times that of copper wire; with the same resistance, CCA wire is about 1/2 heavy of copper wire.
2. Good solderability
CCA wire is clad with a layer of concentric copper, so it has the same solderability as copper wire and doesn't need special treatment as aluminum wire;
3. Light weight
The density of CCA wire is 1/3 of copper wire of the same diameter; very effective to reduce the weight of cables and coils.
Diameter Range:0.15-4.60 mm

Product Type:
Polyester Enameled CCA round wire(PEW);
Polyurethane Enameled CCA round wire(UEW);
Polyesterimide enameled CCA round wire(EIW);
Polyesterimide over-coated with polyamide-imide enameled CCA round wire(EIW/AIW).
