shopping mall Led Area Parking Lot Lights 75w 50w cob 3030 High Power slip fitter FC DLC best price
- Category: >>>
- Supplier: Shenzhen Yaorong Technology Co. Ltd.
Share on (1600423631940):
Product Overview
Description
Yaorong LED shoebox area light Advantages
—————
1.Material environmental protection: Yaorong Technology LED parking lot lights do not contain mercury and other heavy metals. When damaged or destroyed, it will not cause harm or pollution to human health and the environment. It can also be recycled, in line with the characteristics of green and environmental protection.
2.Constant current drive: Yaorong Technology LED parking lights adopt constant current IC drive technology, which can make the drive circuit still have extremely high conversion efficiency under the premise of maintaining good constant current output characteristics.
3.Strong heat dissipation performance: The LED parking lot lamp shell design of Yaorong Technology increases the heat dissipation area. The lamp housing has good heat dissipation characteristics and also guarantees the requirements of the IP protection level, ensuring the continuous effectiveness of the radiator.
4.Intelligent control: Yaorong Technology LED parking lot lights have automatic control energy-saving devices, which can reduce the power as much as possible and save energy under different lighting conditions. It can realize computer dimming, time-segment control, light control, temperature control, automatic inspection and other humanized functions.
5.Reliable quality: Yaorong Technology LED parking lot lights are made of high-quality components, and each LED has a separate over-current protection, which can effectively reduce the failure rate without worrying about damage.
6.IP65 Waterproof: Yaorong Technology’s LED parking lights have passed IP65 water-proof certification and are sealed with silicone rubber seals, which can easily face various harsh environments, allowing you to use them with confidence.
Yaorong LED shoebox area light Certification
—————
Yaorong LED shoebox area light Parameters
—————
| 6th GEN Slim LED Area Light | |||
| Model | CRI | Luminous Flux | Power |
| YR-PL322-W050 | ≥70 | 6500LM | 50W |
| YR-PL322-W100 | ≥70 | 10400LM | 100W |
| YR-PL322-W150 | ≥70 | 13000LM | 150W |
| YR-PL322-W200 | ≥70 | 19500LM | 200W |
| YR-PL322-W240 | ≥70 | 26000LM | 240W |
| YR-PL322-W300 | ≥70 | 31200LM | 300W |
| CCT | 30K/40K/50K/60K/70K | ||
| Warranty | 5 years | ||
| Temperature | -40°~45° | ||
| Power Efficiency | ≥0.9 | ||
| Protection level | IP65 | ||
| Beam angle | 90°*140°/120° | ||
| Shell Color | Bronze/Black/Silver/White/Customized Color | ||
| Certification | ETL/DLC/CE/ROHS | ||
Yaorong LED shoebox area light Features
—————
Bracket Angel 180° Adjustable
Built-in Photocell Optional
Twist Lock Photocell Sensor
Bi-level Microwave Sensor Optional
DIP switch design, three wattages can be selected
Compatible With Different Mount Brackets
Options For Optic Lens
—————
Type III ,Type IV ,Type V and flood lens optional
Yaorong LED shoebox area light Distribution Curve
—————
Yaorong LED shoebox area light Distribution Curve
Yaorong LED shoebox area light Distribution Curve
Yaorong LED shoebox area light Distribution Curve
Yaorong LED shoebox area light Distribution Curve
Yaorong LED shoebox area light Distribution Curve
Yaorong FONDA-RTU200 centralized controller Parameters
—————
| FONDA-RTU200 centralized controller | |||
| Name | FONDA-RTU200 centralized controller | Temperature | -40°~85° |
| Power | 12V battery | Sensitivity | -80~-60dBV |
| Communication | Support GPRS communication mode, support Ethernet remote communication mode | Interface | Support RS485, USB and Ethernet communication interface |
| Switch output | Built-in 4 DO switch output, 250VAC/5A | Frequency | 132KHz |
| System | Embedded Linux operating system, clear software structure, Reliable performance, easy to upgrade | Surge immunity | Level 2, Level 3, Level 4 |
| Elec Parameter | Voltage, current, power, factor, electric energy | Protection level | IP65 |
| Dimensions | 288*177*95mm | Antenna type | External |
| Advantages | 1. With LCD display function; 2. Based on a high-performance 32-bit industrial-grade ARM9 as a microcontroller; ? Using a highly reliable Linux operating system as an embedded application platform; 3. Built-in smart meter, realize remote data reading of electric energy and other data, support remote data reading of external electric meter; 4. Fully sealed protective shell, strong anti-interference ability, can withstand high voltage, lightning and high frequency signal interference; | ||
LED shoebox area light Size Atlas
—————
LED shoebox area light Installation Method Atlas
—————
LED shoebox area light Packaging information
—————
| Watage | Product Size(mm/in) | Package Size(mm/in) | N.W(Kg/lb) | G.W(Kg/Lbs) | QTY |
| 50W | 340×322×77.5mm 13.39×12.68×3.05in | 580×400×130mm 22.83×15.75×5.12in | 3.8Kg(8.38lb) | 4.8kg(10.59lb) | 1PCS |
| 100W | 340×322×77.5mm 13.39×12.68×3.05in | 580×400×130mm 22.83×15.75×5.12in | 3.8Kg(8.38lb) | 4.8kg(10.59lb) | 1PCS |
| 150W | 340×322×77.5mm 13.39×12.68×3.05in | 580×400×130mm 22.83×15.75×5.12in | 3.8Kg(8.38lb) | 4.8kg(10.59lb) | 1PCS |
| 200W | 538×354×72mm 21.18×13.94×2.83in | 610×410×130mm 24.02×16.14×5.12in | 5.2Kg(11.47lb) | 6.7kg(14.78lb) | 1PCS |
| 240W | 538×354×72mm 21.18×13.94×2.83in | 610×410×130mm 24.02×16.14×5.12in | 5.2Kg(11.47lb) | 6.7kg(14.78lb) | 1PCS |
| 300W | 538×354×72mm 21.18×13.94×2.83in | 610×410×130mm 24.02×16.14×5.12in | 5.2Kg(11.47lb) | 6.7kg(14.78lb) | 1PCS |
LED shoebox area light Packaging Atlas
—————
Precautions For The Installation Of LED shoebox area light
—————
- Please cut off the power before installation and make sure that the installation part can bear the weight of the lamp.
- In order to prevent the lamp from falling off, please make sure that the installation is correct.
- Please do not use it in a place with corrosive gas.
- Please do not cover any material on the lamp.
- For safety, please connect the ground wire securely.
- This LED lamp has a five-year warranty from the date of purchase.
- However, failures caused by disassembly, modification, or improper construction of this product are not within the scope of this warranty.
Five-year warranty
—————
- Yaorong Technology is committed to providing customers with cost-effective LED lighting products. And provide high-quality after-sales service ahead of peers.
- Yaorong Technology provides a 5-year warranty. However, unauthorized disassembly or destruction of Yaorong Technology LED lighting products will not be eligible for warranty service.
- If you need after-sales service support, please contact our after-sales staff during the warranty period. Yaorong Technology after-sales engineers communicate with you about after-sales matters.
Yaorong LED shoebox area light Case
—————
Yaorong LED shoebox area light Case
Yaorong Company Scene
—————
Yaorong Exhibition Hall--Qualification Certification
Yaorong Office environment
Yaorong Factory Scene
—————
Yaorong R&D Workshop
Yaorong Factory
