Factory Custom Size LCD Screen 7 Inch Monitor Touchscreen, TFT Monitor Pantallas LCD Touch Screen Portable Screen Monitor
- Category: >>>
- Supplier: Hengrui (shenzhen) Technology Co. Ltd.
Share on (1600423677325):
Product Overview
Description
Customizable
Supportable customized solutions:
☑ Logo(Packing , Logo)
☑ Product Color
☑ Specification/Function Customization
☑ Interfaces Customization
☑ The case mould Customization
☑ Product Color
☑ Specification/Function Customization
☑ Interfaces Customization
☑ The case mould Customization
We can support OEM/ODM service, the process of customization is following:
1: Provide your specific requirement.
2: Our design engineers draw the design draft.
3: You confirm the design draft.
4: We start produce it.
2: Our design engineers draw the design draft.
3: You confirm the design draft.
4: We start produce it.
Products Description
Upgraded! 7 inch IPS Touchscreen Monitor, Support Brightness & Display Direction Adjustment, TeNizo 1024x600 Capacitive Touch Screen HD HD-MI LCD Display for Raspberry Pi Zero/2/3/4 B A+ B+ BB Black, Banana Pi, Drive Free
* ⚡️【 High-quality Raw Materials, Excellent Precise Workmanship, Continuously Optimized & Upgraded 】: For the driver board: upgrade to adopt ENIG technology, high-end matt black appearance; For internal display screen: upgrade to adopt premium 1024x600 IPS screen with bright color, Contrast Ratio: 800:1, Brightness: 400cd/m² adjustable, Level Index up to 16.7M(8-bit). Detailed instructions, complete accessories, and timely customer service.
* ⚡️【SUPPORT BRIGHTNESS ADJUSTMENT】Features MENU buttons on the back of the monitor, supports adjustment of brightness, contrast and display direction according to the environment you need, show you a bright and colorful display! Compared with the others cannot support brightness adjustment, which really brings you greater convenience.
* ⚡️【 DETACHABLE COPPER COLUMN STAND 】 Equipped with the copper column tripod, which is detachable. there is no any problems no matter will you install it on the wall, in the pc case, or even put it on the desktop. The tripod is stable and it‘s that easy to install. Support Windows/mac OS system plug and play, no program or software support is required.
* ⚡️【 WIDELY COMPATIBLE 】 It’s not only a for Raspberry Pi 4/3/2/1/3B+/BB, Banana Pi. also compatible with like Ubuntu, Retro Pi, Debian, Kali, Windows 7/8/10, PC, Mac, Laptop, TV; Also compatible with Switch/XBOX/PS4. For any issues. 24-hour Professional tech support, Email: support@tenizo-display.com.
Recommend Products
Product Paramenters
Model | R7H-S/R7H-SB/R7H-ST/R7H-STB |
Size | 7.0inch TFT-LCD |
Type | TN, Normally White |
Resolution | 1024×600 |
Visual Angle | 178°Full View Angle |
Dimension | 164.9x124.2(mm) |
Display Dimension | 154.21(W)x85.92(H)mm |
Thickness | 5.6mm/11.6mm(Plus HD-MI) |
Color Gamut | 50% NTSC |
Display Colors | 16.7M(8-bit) |
Refresh Rate | 60Hz |
Response Time | 3-5ms |
Size Ratio | 16:9 |
Contrast Ratio | 800:1 |
Surface Luminance | 400cd/m2 |
Touch Function | R7-S/R7-SB: No R7-ST/R7-STB: Yes |
Touchscreen Type | Capacitive |
Touch Chip | GT911 |
Touch Points | 5 Point Touch |
Interface | 1xHD-MI, 2xUSB(one for power supply, another one for touch & power supply ) |
OSD Keyboard | Available for OSD control |
Backlight Switch | Yes |
With Stand | Include |
With Case | R7-STB: Include |
Product Weight | 161g |
Applications | Applications: DIY Projects/ Raspberry Pi/ 3D Printer display/ Ubuntu/ Kali/ Windows10/8/7/ mac OS system |
