wholesale products 5g modem ZC 521 ONUs GPON for f670L eg8145v5
- Category: >>>
- Supplier: Changsha Silun Network Technology Co. Ltd.
Share on (1600424071348):
Product Overview
Description
Product Description
Product Name | XPON Dual band ONU |
Antenna | 4 |
Interface | 4GE+2.4G&5G WIFI |
Antenna Gain | 5Dbi |
Product performance description
产品性能介绍说明
产品性能介绍说明
ZC-521 is a dual-mode（XPON） optical network terminal (ONT) supports automatic switching between GPON and EPON modes, is designed for the fiber to the home (FTTH) scenarios. ZC-521 complies with the ITU-T G.984 standard and IEEE802.3ah Standard, It has 10Mbps/100Mbps/1000Mbps adaptive GE interfaces, complying with IEEE802.3-2005 standards. The device offers 4* GE, 1USB and 2*2 11n+2*2 11ac wifi. It can provide serivces for video and highspeed internet access.
Smart interconnection
*Smart Wi-Fi coverage
* SIP/H.248 autonegotiation
* Any port any service
* Parental control
* L2/L3 forwarding: 1G uplink, 2G downlink
Layer 3 Features
* PPPoE/Static IP/DHCP/Bridge
* NAT/NAPT
* Port forwarding
* ALG, UPnP
* DDNS/DNS server/DNS Client
* IPv6/IPv4 dual stack,DS-Lite and IPv6 SPI
* Static/Default routes
* Multiple services on one WAN port
Other Function
* IGMP v2/v3 proxy/snooping
* MLD v1/v2 snooping
* 802.1P priority
* Ethernet port rate limitation
* Broadcast packet ratelimitation
* SP/WRR/SP+WRR
User Network Interface（UNI）：4GE+2.4G&5G WIFI+1USB | ||
Ethernet Port | Ethernet port-based VLAN tags and tag removal | |
1:1 VLAN, N:1 VLAN, or VLAN transparent transmission | ||
QinQ VLAN | ||
MAC address learning | ||
Auto-adaptive 10 Mbit/s, 100 Mbit/s or 1000 Mbit/s | ||
WLAN | IEEE 802.11 b/g/n (2.4G) | |
IEEE 802.11 a/n/ac (5G) | ||
2 × 2 MIMO (2.4G&5G) | ||
Antenna gain: 5 dBi，6*extenal antenna | ||
2.4G&5G concurrent | ||
Air interface rate:300 Mbit/s (2.4G); 867 Mbit/s(5G) | ||
PON interface（NNI）：1 x PON interface | ||
Optical port | GPON/EPON mode adaptive ITU-T G.984 GPON standards，Support for backward compatibility with IEEE 802.3ah EPON Single mode fiber | |
Optical connector | SC/APC | |
Receiving Sensitivity | -28dBm | |
Overload optical power | -8 dBm | |
Transmitting Optical Power | 0.5~5dBm | |
Transmit rate | GPON:2.488Gbps downstream; 1.244Gbps upstream EPON:1.25Gbps downstream；1.25Gbps upstream | |
Wavelength | Receiving（DOWN）:1490nm；Transmitting（UP）:1310nm | |
Authentication | consistent with the SN or Password authentication defined in G.984.3;LOID authentication；MAC authentication | |
Physical Performance | ||
Dimensions (H x W x D) | 41mm*184mm*139mm | |
Working temperature | 0°C ~ 40°C | |
Working humidity | 5% RH to 95% RH (non-condensing) | |
Power adapter input | 100–240 V AC, 50 / 60 Hz | |
System power supply | 12V DC, 1.5 A | |
Power consumption | <15W | |
Related Products
Packing&Shipping
packaging:
1. All products will be packed in carton , so the product can get effective protection to avoid damage.
2. Packaging according to customer requirement
Shipping:
1. We shipping via DHL / FedEx / TNT/etc for samll orders. Yow can get your packages in about 3-5 days all over the world.
2. For big order, we will arrange Air cargo for your shipment, so it will be much cheaper than DHL, UPS etc.
3. You can choose your own shipping agent, we will provide good cooperation for it.
1. All products will be packed in carton , so the product can get effective protection to avoid damage.
2. Packaging according to customer requirement
Shipping:
1. We shipping via DHL / FedEx / TNT/etc for samll orders. Yow can get your packages in about 3-5 days all over the world.
2. For big order, we will arrange Air cargo for your shipment, so it will be much cheaper than DHL, UPS etc.
3. You can choose your own shipping agent, we will provide good cooperation for it.
Company Introduction
Hunan Zikun Information Technology Co., Ltd. is a provider of information and communication solutions for optical communication technology and video processing technology.
The company can provide users with leading optical communications products and IPTV, system solutions and professional services at home and abroad who dedicates to create the greatest value for customers.
Currently the company’s main business scope includes DWDM, GPON, EPON, switches, IPTV, EOC, passive devices and other products, those are wid-ely used in radio and television cable network, triple play and safe urban security, road facilities, airports, ports, Securities industry, tourism scenic area, school education industry, public security law and politics, medical and health, intelligent community and large and medium-sized enterprises ect... We will make our all efforts to make you succeed and gain benefit from the cooperation with us, as the customers'success is our success. And through our joint efforts, continue to contribute to the development of human science and technology.
The company can provide users with leading optical communications products and IPTV, system solutions and professional services at home and abroad who dedicates to create the greatest value for customers.
Currently the company’s main business scope includes DWDM, GPON, EPON, switches, IPTV, EOC, passive devices and other products, those are wid-ely used in radio and television cable network, triple play and safe urban security, road facilities, airports, ports, Securities industry, tourism scenic area, school education industry, public security law and politics, medical and health, intelligent community and large and medium-sized enterprises ect... We will make our all efforts to make you succeed and gain benefit from the cooperation with us, as the customers'success is our success. And through our joint efforts, continue to contribute to the development of human science and technology.
Our Services & Strength
After-Sales Service
1. We can provide detail documents and remote help for device installation and configuration.
2. Warranty: 1 year. ( After the quality guarantee period began to charge appropriate maintenance service fee.)
3. Our company promises goods enjoy full return due to quality problem since goods delivered within 7 days or 15 days , returned
goods must keep original state and it’s accessories are complete.
1. We can provide detail documents and remote help for device installation and configuration.
2. Warranty: 1 year. ( After the quality guarantee period began to charge appropriate maintenance service fee.)
3. Our company promises goods enjoy full return due to quality problem since goods delivered within 7 days or 15 days , returned
goods must keep original state and it’s accessories are complete.
FAQ
Q: Can I have a sample order for this product?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q:Do you have any MOQ limit for sample order?
A: Low MOQ, 1pc for sample checking is available
Q: How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q: What is your delivery time?
A: It is in 3-5 working days since the payment confirmed . If quantity is more than 1000pcs /order, it will need extra 1-2 weeks .
Q: Do you offer guarantee for the products?
A: Yes, we offer 1 year warranty to our formal products.
Q: Could we make a visit to your factory?
A: Yes,sure, you are welcomed .
Our Advantages:
All the products 100% Original / Ability for OLT & ONU configuration and Firmware updating./ UK |US|AU|EU Power Adapter Available
/ English Firmware Setup Interface.
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q:Do you have any MOQ limit for sample order?
A: Low MOQ, 1pc for sample checking is available
Q: How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q: What is your delivery time?
A: It is in 3-5 working days since the payment confirmed . If quantity is more than 1000pcs /order, it will need extra 1-2 weeks .
Q: Do you offer guarantee for the products?
A: Yes, we offer 1 year warranty to our formal products.
Q: Could we make a visit to your factory?
A: Yes,sure, you are welcomed .
Our Advantages:
All the products 100% Original / Ability for OLT & ONU configuration and Firmware updating./ UK |US|AU|EU Power Adapter Available
/ English Firmware Setup Interface.
