Zhongyi 2021 New Sheet Metal Bending Machine CNC Panel Bender Hot Sale Sheet Bender for Kitchen Cabinet
- Category: >>>
- Supplier: Anhui Zhongyi Machine Tool Manufacturing Co. Ltd.
Share on (1600425207130):
Product Overview
Description
Product Description
Intelligent flexible bending center is an automation product developed for sheet metal industry to improve production efficiency,reduce labor intensity and enhance corporate image.The equipment has 4.0 industrial architecture,intelligent flexibility,fast working speed,rapid workpiece forming,high consistency,low power consumption,simple daily maintenance,high degree of automation and simple operation.It is suitable for processing stainless steed,cold plate and aluminum plate and other industries,can bend right angle,non right angle,arc,up fold,dead edge and other complex shape combination,and can be compatible with manual loading and unloading or robot loading an unloading or manipulator loading and unloading.
Model | ZY-2000 |
Feeding mode | pressure arm type |
Bending length (mm) | 2000 |
Max bending height (mm) | 170 |
Mix bending height(mm) | 4 |
Mix forming size of four sides (mm) | 300*300 |
Mix forming size of one side(mm) | 160 |
Mix arc radius(mm) | 1.2 |
Mix continuous bending speed(s) | 0.25 |
Bending angle(°) | 0-180 |
Number of control axes (axis) | 10 |
Axis positioning accuracy(mm) | 0.01 |
Max feeding speed (m/min) | 120 |
Average power (KW) | 2 |
Total power (KW) | 55 |
Bending die (mm) | stardard |
Equipment size (mm) | 5780*3100*2300 |
The machine is mainly used for cutting flat bar , profile, punching hole and notching.
It can widely used in Shipyard ,Electric, Bridge, Automobile, Hoisting＆Transportation, Metal Construction and other machinery factories etc.
Description of application effect
Flat bar cutting ,punching hole and notching work can be performed on the machine within the rated specification .
With extra equipment,the machine is able to cut, punch and bend in special shape . The machine adopted hydraulic driving system and has a performance and overload protecting device .
Product Paramenters
Material properties | Max thickness(mm) | ||
Stainless steel | 0.3-1.0 | ||
Cold plate | 0.3-1.5 | ||
Aluminum plate | 0.3-2.0 | ||
Details Images
Energy Saving :
Compared with hydraulic solutions, it can reduce energy consumption and carbon dioxide emissions by 64%.
Extremely Low Maintenance Costs :
The maintenance cost can be reduced by 65% compared with the traditional hydraulic bending machine.
Higher Accurracy and Quality :
Excellent bending accuracy and surface quality&high repeatability.
Higher Productiviy :
Productivity can be maximized without skilled operators. Compared with traditional bending machine and manipulator bending machine, it has higher productivity and faster programming efficiency.
Protection of the Operator :
What being processed is transmitted from the external workbench to ensure the safety of operators.
Packing&Shipping
Packaging Details
The normal package is plastic film packaging or wooden box , we will pack it according to customers special request.
The normal package is plastic film packaging or wooden box , we will pack it according to customers special request.
Company Introduction
ZHONGYI Industrial hydraulic iron worker have been designed and built to the highest quality standards in the industry.This profitable machine will serve any grueling fabrication shop for decades to come.
The machine by the European Union CE certification and ISO quality system certification
The machine by the European Union CE certification and ISO quality system certification
Our Services & Strength
After-sales service:
Machine is simple, generally, user can understand how to operate. There is operation instruction and disc.
Welcome to our factory to learn how to operate our machine, we will give good training and it's for free.
Our engineer is available for user. If there is requirement, our engineer can go to user factory, and adjust machine, give good training to user.
Machine is simple, generally, user can understand how to operate. There is operation instruction and disc.
Welcome to our factory to learn how to operate our machine, we will give good training and it's for free.
Our engineer is available for user. If there is requirement, our engineer can go to user factory, and adjust machine, give good training to user.
Certifications
Why Choose Us
Long History
Our company was founded in 2002,has a history of nearly 20 years.
We have been in a leading position in China's machinery manufacturing industry.
We are the first enterprise in Anhui province to produce hydraulic ironworker machines.
We are the first enterprise in Anhui province to produce hydraulic ironworker machines.
Factory Direct Sale
We have a large factory and all the machines are sold directly from the factory. Ensuring the quality of each machine.
In addition,we have a complete after-sales service system.
Good Reputation
Alibaba assessed 12 years Gold Supplier for ironworker.
Inspected by the Inspection Institution of Bureau Veritas Certification.
100% QC inspection Before Shipment.
Best Quality & Best Service with Competitive price.
Inspected by the Inspection Institution of Bureau Veritas Certification.
100% QC inspection Before Shipment.
