  • ET5301 Direct Sales Battery Tester Digital Lcr Meter Multimeter Inductance Capacitance Meter
ET5301 Direct Sales Battery Tester Digital Lcr Meter Multimeter Inductance Capacitance Meter
ET5301 Direct Sales Battery Tester Digital Lcr Meter Multimeter Inductance Capacitance Meter
ET5301 Direct Sales Battery Tester Digital Lcr Meter Multimeter Inductance Capacitance Meter
ET5301 Direct Sales Battery Tester Digital Lcr Meter Multimeter Inductance Capacitance Meter
ET5301 Direct Sales Battery Tester Digital Lcr Meter Multimeter Inductance Capacitance Meter
ET5301 Direct Sales Battery Tester Digital Lcr Meter Multimeter Inductance Capacitance Meter
ET5301 Direct Sales Battery Tester Digital Lcr Meter Multimeter Inductance Capacitance Meter

ET5301 Direct Sales Battery Tester Digital Lcr Meter Multimeter Inductance Capacitance Meter

Share on (1600425238251):


Price:$257.81 - $296.88

Quantity:


Product Overview

Description







PRODUCT DETAILS






Model
ET5300A
ET5300
ET5301
Rated input
Power
200W
400W
Input voltage
0-150V
Input current
0-30A
0-40A
0-60A
CV mode
Range
0.1~19.999V,0.1~150.00V
Resolution
1mV,10mV
Accuracy
±(0.05%+0.02%FS)
CC mode
Range
0~3.000A
0~6.000A
0~30.00A
0~40.00A
0~60.00A
Resolution
1mA,10mA
Accuracy
±(0.05%+0.05%FS)
CR mode
Range
0.05Ω~1 kΩ，1 kΩ~4.5kΩ
Resolution
10mΩ，100mΩ
Accuracy
±(0.1%+0.5%FS)
CP mode
Range
0~200W
0~400W
Resolution
10mW
Accuracy
±(0.1%+0.5%FS)
Tran Test
Mode
CC，CV
T1&T2
50ms~60s；

Battery Test
Accuracy
CC，CR
Discharge mode
9999Ah
Maximum discharge capacity
1mA，10mA，10mΩ，100mΩ
Range of measurement
Voltage read-back value
Range
0~19.999V,0 ~150.00V
Resolution
1mV,10mV
Accuracy
±(0.05%+0.1%FS)
Current read-back value
Range
0~3.000A
0~6.000A
0~30.00A
0~40.00A
0~60.00A
Resolution
1mA,10mA
Accuracy
±(0.05%+0.1%FS)

Power read-back value
Range
200W
400W
Resolution
10mW
Accuracy
±(0.1%+0.5%FS)
Scope of protection
Overvoltage protection
＞21V or 155V overvoltage protection
Overcurrent protection
＞3.1A or 31A input cut off
＞3.1A or 41A input cut off
＞6.1A or 61A input cut off
Overpower protection
210W
410W
Over-temperature protection
85℃
Model
ET5302
ET5303
ET5304
Rated input
Power
400W
400W（200W*2）
Input voltage
0-500V
0-150V
Input current
0-15A
0-30A
0-60A(30A*2)
CV mode
Range
0.1~19.999V,0.1~500.00V
0.1~19.999V，0.1~150.00V
Resolution
1mV,10mV
1mV，10mV
Accuracy
±(0.05%+0.02%FS)
±(0.05%+0.02%FS)
CC mode
Range
0~3.000A,0~15.00A
0~3.000A,0~30.00A
0.1~19.999V，0.1~150.00V
Resolution
1mA,10mA
1mV，10mV
Accuracy
±(0.05%+0.05%FS)
±(0.05%+0.02%FS)
CR mode
Range
0.05Ω~1 kΩ，1 kΩ~4.5kΩ
0.05Ω~1 kΩ，
1 kΩ~4.5kΩ
Resolution
10mΩ，100mΩ
10mΩ，100mΩ
Accuracy
±(0.1%+0.5%FS)
±(0.1%+0.5%FS)
CP mode
Range
0~400W
0~200W
Resolution
10mW
10mW
Accuracy
±(0.1%+0.5%FS)
±(0.1%+0.5%FS)
Tran Test
Mode
CC，CV
CC，CV
T1&T2
50ms~60s；
50ms~60s；

Battery Test
Accuracy
CC，CR
CC，CR
Discharge mode
9999Ah
9999Ah
Maximum discharge capacity
1mA，10mA，10mΩ，100mΩ
1mA，10mA，
10mΩ，100mΩ
Range of measurement
Voltage read-back value
Range
0~19.999V,0 ~500.00V
0~19.999V,0 ~150.00V
Resolution
1mV,10mV
1mV,10mV
Accuracy
±(0.05%+0.1%FS)
±(0.05%+0.1%FS)
Current read-back value
Range
0~3.000A,0~15.00A
0~3.00A,0~30.00A
0~3.000A,0~30.00A
Resolution
1mA,10mA
1mA,10mA
Accuracy
±(0.05%+0.1%FS)
±(0.05%+0.1%FS)
Power read-back value
Range
400W
200W
Resolution
10mW
10mW
Accuracy
±(0.1%+0.5%FS)
±(0.1%+0.5%FS)
Scope of protection
Overvoltage protection
＞21V or 510V overvoltage protection
＞21V or 155V overvoltage protection
Overcurrent protection
＞3.1A or 16A input cut off
＞3.1A or 31A input cut off
＞3.1A or 31A input cut off
Overpower protection
410W
210W
Over-temperature protection
85℃
85℃
