WLN KD C1000 10W uhf transceiver

Product Overview

Description



Anytalk Two way radio transceiver, the legitimate use of green and healthy.

Walkie Talkie the Green public radio, can completely relieve your worries!

•UHF(400-470MHz)
•Time Out Timer(TOT)
•Low Voltage Alert
•Squelch Level
•Scan
•CTCSS/CDCSS
•Chinese and English Voice Prompt

SPECIFICATION	SPECIFICATION
Frequency Range	UHF:400-470MHz
Supply Power	DC3.7V
Operation Temperature	-20℃ - +60℃
Frequency Engender	PLL
Memory Channel	16
Antenna	Internal Antenna
Antenna Impedance	50Ω
Work Mode	Co-frequency or Differ-frequency Simplex Communication
Ground Method	Cathode
Dimension	136X56X22mm
Weight	90g



TRANSMITTER	TRANSMITTER
Output Power	10W
Modulation Mode	FM(F3E)
Max.Frequency Deviation	≤5KHz
Sparious Radiation	<-60dB
Preemphasis Character	6dB
Emission Current	≤1000mA



RECEIVER	RECEIVER
Sensitivity	≤0.16uV(12dB SINAD)
Squelch Sensitivity	≤0.2uV
Intermodulation Interference Resistance	50dB
Audio Power	≥300mW
Receiving Current	≤100mA
Standby Current	20mA









Using rechargeable walkie-talkie for the first time, please charge for 16 hours.

Turn off your computer before removing the battery.

Please do not use hand to pick up the antenna, hold the antenna will affect the effective wireless intercom call range.

Use the walkie-talkie, you should keep it vertical distance of 5.0 to 7.0 cm, and keep your face.

Please try to use while driving handsfree speaker and the closing words.

Keep your intercom televisions, computer monitors and other screen to maintain a distance greater than 10cm, to avoid being magnetized.

The interphone Do things together with other metal-containing storage.

Walkie-talkies may interfere with some hearing aids, with your hearing aid manufacturer to discuss alternatives.

Try to place in the medical walkie-talkie off, so as not to affect the use of medical equipment.

Do not use in airports and on aircraft. If so, prohibited driving the car to the side of the road and then.

In potentially explosive areas must remain shut down, unless it is dedicated intercom dangerous areas (for example, Factory Mutual, CAS, or UL certified).
