New Original Quectel RM510Q GL 5G mmWave m.2 module supports 5g NSA and SA modes
- Category: >>>
- Supplier: Shi,Di,Fen,(Shenzhen),Technology,Co.,Ltd.
Share on:
Product Overview
Description
New Original Quectel RM510Q-GL 5G mmWave m.2 module supports 5g NSA and SA modes
Overview
Quectel RM510Q-GL is a 5G module that is specially optimized for IoT/eMBB applications. Adopting 3GPP Release 15, it supports both 5G NSA and SA modes. Designed in M.2 form factor, RM510Q-GL can be easily embedded in customers’ applications. RM510Q-GL is an industrial-grade module for industrial and commercial applications only.
Key Benefits
- 5G/4G/3G Multi-mode module with M.2 form factor, optimized for IoT and eMBB applications
- Supports ENDC 3x carrier aggregation and 256QAM, DL Cat 16/ UL Cat 18
- Worldwide 5G and LTE-A coverage
- Both NSA and SA modes
- Multi-constellation GNSS receiver available for applications requiring fast and accurate fixes in any environment
- Feature refinements: DFOTA and VoLTE (optional)
- 5G DL 4×4 MIMO, UL 2×2 MIMO
- 4G DL 4×4 MIMO
- LTE LAA B46 Support
Supported Frequency Bands
| 5G | 5G NR | 3GPP Release 15 NSA/SA operation, Sub-6 GHz, mmWave |
| 5G NR NSA | n1/n2/n3/n5/n7/n8/n12/n20/n25/n28/n38/n40/n41/n48*/n66/n71/n77/n78/n79/n257/n258/ n260/n261 | |
| 5G NR SA | n1/n2/n3/n5/n7/n8/n12/n20/n25/n28/n38/n40/n41/n48*/n66/n71/n77/n78/n79 | |
| MIMO | DL: 4 × 4 MIMO on n1/n2/n3/n7/n25/n38/n40/n41/n48/n66/n77/n78/n79 | |
| LTE | LTE Category | DL Cat 20/ UpLink Cat 18 |
| LTE-FDD | B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/ B29/B30/B32/B66/B71 | |
| LTE-TDD | B34/B38/B39/B40/B41/B42/B43/B48 | |
| LAA | B46 (only support 2 × 2 MIMO) | |
| DL 4 × 4 MIMO | DL: 4 × 4 MIMO on B1/B2/B3/B4/B7/B25/B30/B32/B34/B38/39/B40/B41/B42/B43/B48/B66 | |
| UMTS | WCDMA | B1/B2/B3/B4/B5/B6/B8/B19 |
