XB2/XB4/XB5 Key stay put hot selling electronic 2 position 3 position key stay put selector switch key lock
- Category: >>>
- Supplier: Zhejiang Ninuo Electical Co. Ltd.
Share on (1600426546347):
Product Overview
Description
XB2, XB4, XB5 series Push Buttons are suitable for industrial control circuits with AC 50Hz or 60Hz, rated operating voltage to
380V and DC operating voltage to 250V, and are used for controlling electromagnetic starters, contactors, relays and other
electrical circuits.
Detailed Images
Product Deatils
Technical Parameters | ||||||||||
Nominal insulation voltage | 380V | |||||||||
Rated current | 10A | |||||||||
Rated operational voltage | 380V | 250V | 240V | 125V | ||||||
Rated operational current | AC-15 | 2.5A | 3A | |||||||
DC-13 | 0.27A | 0.55A | ||||||||
Operating temp. | -25°c- +55°c | |||||||||
Contact action | NO or NC | |||||||||
Contact resistance | ≤ 50mΩ | |||||||||
Short-circuit protection | RT16-10A | |||||||||
LED | Green / Red / Yellow / Blue / White | |||||||||
LED Rated voltage | AC/DC 6V | AC/DC 12V | AC/DC 24V | AC 110V / 220V / 380V | ||||||
Common description for waterproof push button switch | ||||||
Momentary | When you push switch and then move your finger, the actuator will back to the original position. | |||||
Latching | When you press the button, it keeps pressed until you press again | |||||
Contact | The contact is a conducting part designed to be united by pressure to another conducting part for the purpose of carrying current | |||||
N.O. | Normally Open circuit | |||||
N.C. | Normally Closed circuit | |||||
SPST | Single Pole Single Throw | |||||
DPDT | Double Pole Double Throw | |||||
Product Description
XB4 series are suitable to industrial control circuit with AC 50 Hz or 60Hz,0-380V rated voltage and 0-220V DC operating voltage,
used for the control of magnetic starter, contactor, relay and other electric circuit.
Structure The switch unit slow-break and self-cleaning. It uses modular combustion mode and you can combine from one to eight
switch units optional, so can make the product meet requirement of many special control circuits. It can be connected more safely
and installed firmly.
Technical Specification:
1.Operating temperature:-25C-55C(no freezing)The average value in 24 hrs no more than+35℃
2.Operating humidity:45~85%rh; 45~85%rh(no condensation)
3.Contact resistance: ≤30mΩ
4.Insulation resistance: ≥100M
5.The highest Dielectric streagth:3000VAc50hz
6.Vibration resistance: 50hz,Amplitude1.0mm
7.Shock resistance: >10g
8.Life---Mechanical: Momentary:>2000000 times: alternate, selector>1000000 times: key-lock, emergency>1000000 times
9.Life---Electrical: >500000tmes
10.Terminal: Screw terminal, connecting ability:min:1x0.5mm2 max:1x2. 5mm2 or 2x1.5 mm2(with or without connecting link)
11.Operation: 80gf-2200gf,according to the quantity of switch units Operation travel: About 5. 5mmm (For push button type)
12.Pollution Degree: 3 degree
Company Information
We are the experienced manufacturer of industrial electric products for years.Manhua Electric Co.,Ltd.
It was established in 2009 and domestic business started in 1980s.
At present, our main products are timer switches, timer, relay, sockets and surge arrestors.
This year, we have started to do more jobs on the electric products for solar and ofgrid solar powersystem.
Our products have exported to the market of Germany and USA since the year of 2005, and
till now the products have stable growing market in Germany, Spain,USA, South America, CIS
countries and Thailand...
We have built our divisions/agents in Chicago USA, Frankfurt Germany and Dubai.
We bring trust, comfort and benefits for our customer. Over the years, we have always done the
humane management. Our staff has played the full role in the innovation and management.
We have the experienced team of research and development in the electronic products.
XB4 series are suitable to industrial control circuit with AC 50 Hz or 60Hz,0-380V rated voltage and 0-220V DC operating voltage,
used for the control of magnetic starter, contactor, relay and other electric circuit.
Structure The switch unit slow-break and self-cleaning. It uses modular combustion mode and you can combine from one to eight
switch units optional, so can make the product meet requirement of many special control circuits. It can be connected more safely
and installed firmly.
Technical Specification:
1.Operating temperature:-25C-55C(no freezing)The average value in 24 hrs no more than+35℃
2.Operating humidity:45~85%rh; 45~85%rh(no condensation)
3.Contact resistance: ≤30mΩ
4.Insulation resistance: ≥100M
5.The highest Dielectric streagth:3000VAc50hz
6.Vibration resistance: 50hz,Amplitude1.0mm
7.Shock resistance: >10g
8.Life---Mechanical: Momentary:>2000000 times: alternate, selector>1000000 times: key-lock, emergency>1000000 times
9.Life---Electrical: >500000tmes
10.Terminal: Screw terminal, connecting ability:min:1x0.5mm2 max:1x2. 5mm2 or 2x1.5 mm2(with or without connecting link)
11.Operation: 80gf-2200gf,according to the quantity of switch units Operation travel: About 5. 5mmm (For push button type)
12.Pollution Degree: 3 degree
Company Information
We are the experienced manufacturer of industrial electric products for years.Manhua Electric Co.,Ltd.
It was established in 2009 and domestic business started in 1980s.
At present, our main products are timer switches, timer, relay, sockets and surge arrestors.
This year, we have started to do more jobs on the electric products for solar and ofgrid solar powersystem.
Our products have exported to the market of Germany and USA since the year of 2005, and
till now the products have stable growing market in Germany, Spain,USA, South America, CIS
countries and Thailand...
We have built our divisions/agents in Chicago USA, Frankfurt Germany and Dubai.
We bring trust, comfort and benefits for our customer. Over the years, we have always done the
humane management. Our staff has played the full role in the innovation and management.
We have the experienced team of research and development in the electronic products.
Product Deatils
Notice:Can not used in the electric environment with frequency conversion , high frequency, strong harmonic interference signal.
Type | AD101-22VAMS |
Brand name | NIN |
Place of origin | Zhejiang Province, China(Mainland) |
Mounting diameter | 22mm |
Voltage measuring range | AC 50-500V |
Ampere measuring range | 0-100A |
Color | Red Green Yellow Blue White |
Accuracy | ± 2% V A |
Display resolution | 1V 1A |
Sample rate | About 1time/s |
Input circuit power loss | <2VA |
No input signal hint message | V display 000 A display 000 |
