Italy Baltur Burner TBL 45P ~ 60P Best Quality Low Pressure Diesel Powered Mushroom Subbstrate Sterilizer
- Category: >>>
- Supplier: Henan Zhongde Environmental Protection Technology Co. Ltd.
Share on (1600427358109):
Product Overview
Description
Product Description
(Baltur) burner is a general term for devices that enable fuel and air to be ejected and burned in a certain way. Burners are divided into industrial burners, combustors, civil burners and special burners according to types and application fields. Made of high temperature resistant material. The burner has the properties of high atomization efficiency, low noise, stable flame, high absorption sensitivity and determination precision.
Product Details
Technology and performance characteristics
● Light oil burner.
● Two stage operation (high / low fire).
● Suitable for any type of combustion chamber.
● Mechanical pressure atomization.
● The best combustion parameters can be obtained by adjusting the combustion air and combustion head.
● Combustion engine emission reaches European standard class II.
● Hinge connection, it is simple and convenient to maintain and adjust the internal parts of the combustion head without removing the burner.
● Printed circuit board for electrical connection, including small fire / large fire selection button, power supply and temperature controller connected 7-hole plug and 4-hole plug for two-stage fire control.
● The sliding flange matched with various boiler flanges can adjust the position where the burner extends into the boiler.
● Steel adjustable combustion head with blast pipe and flame diffuser.
●The hydraulic regulator is used to control the damper baffle to regulate the air flow of the first and second sections; In DACA version, the damper baffle is controlled by the servo motor.
● Gear pump with pressure regulator, pressure tap and safety valve.
● Photoresist detects flame.
● The LED light of the program controller can indicate operation, fault and other working states.
● The fan motor meets the European standard IE1.
● Electrical protection grade IP40.
● Two stage operation (high / low fire).
● Suitable for any type of combustion chamber.
● Mechanical pressure atomization.
● The best combustion parameters can be obtained by adjusting the combustion air and combustion head.
● Combustion engine emission reaches European standard class II.
● Hinge connection, it is simple and convenient to maintain and adjust the internal parts of the combustion head without removing the burner.
● Printed circuit board for electrical connection, including small fire / large fire selection button, power supply and temperature controller connected 7-hole plug and 4-hole plug for two-stage fire control.
● The sliding flange matched with various boiler flanges can adjust the position where the burner extends into the boiler.
● Steel adjustable combustion head with blast pipe and flame diffuser.
●The hydraulic regulator is used to control the damper baffle to regulate the air flow of the first and second sections; In DACA version, the damper baffle is controlled by the servo motor.
● Gear pump with pressure regulator, pressure tap and safety valve.
● Photoresist detects flame.
● The LED light of the program controller can indicate operation, fault and other working states.
● The fan motor meets the European standard IE1.
● Electrical protection grade IP40.
Product specification
Power (kW) | Light oil flow (kg/h) | Burner model | Maximum viscosity (˚E@20˚C) | Power Supply | Motor power (kW) | Package size (L x P x H mm) | Weight (kg) |
160~450 | 13.8 ~ 38 | TBL 45P | 1.5 | 1N AC 50Hz 230V | 0.50 | 1000 x 600 x 510 | 34 |
160~450 | 16.9 ~ 38 | TBL 45P DACA | 1.5 | 1N AC 50Hz 230V | 0.50 | 1000 x 600 x 510 | 34 |
250~600 | 21.0 ~ 50.6 | TBL 60P | 1.5 | 3N AC 50Hz 400V | 0.65 | 1000 x 600 x 510 | 36 |
250~600 | 21.0 ~ 50.6 | TBL 60P DACA | 1.5 | 3N AC 50Hz 400V | 0.65 | 1000 x 600 x 510 | 36 |
