JIECANG 12V 24V TV Lifting Stepper Servo Motor Magnetic Synchronous Linear Actuator
- Category: >>>
- Supplier: Zhejiang Jiecang Linear Motion Technology Co. Ltd.
Share on (1600427755426):
Product Overview
Description
Products Description
Features
1. DC 24V permanent magnet motor
2. The maximum thrust is 4000N, the maximum pull is 3000N
3. The shell color is gray or black optional
4. Protection IP20
5. Orbital push rod, the nut can slide on the aluminum profile
6. The average noise level is less than 60dB (environmental noise≤40dB)
7. Built-in electronic limit switch
8. Certification: UL, CE
2. The maximum thrust is 4000N, the maximum pull is 3000N
3. The shell color is gray or black optional
4. Protection IP20
5. Orbital push rod, the nut can slide on the aluminum profile
6. The average noise level is less than 60dB (environmental noise≤40dB)
7. Built-in electronic limit switch
8. Certification: UL, CE
Usage
Max 10% or 2 minutes continues use followed by 18 minutes not in use
Ambient temperature: +5 º to +40 º
Storage temperature: -10º to -50 º
Atmospheric pressure:700-1060hPa
Company Profile
FAQ
Q: Do you get the relevant certifications?
A: Yes, so far, we have got certification of CE, TUV, UL, PSE, KC, SAA, ROSH, ISO9001:2015, ISO14001:2015 and so on.
Q: May I have a sample order before bulk one?
A: Of course, we can provide a sample for you.
Q: What is the shipping port?
A: Shanghai or Ningbo Port.
Q: How can I get the quotation?
A: You need to send up information, we will let our regional sales to contact with you, and the details you should to give: email address, telephone number, material, size, input, Load capacity, quantity, color, speed or frequency, etc
A: Yes, so far, we have got certification of CE, TUV, UL, PSE, KC, SAA, ROSH, ISO9001:2015, ISO14001:2015 and so on.
Q: May I have a sample order before bulk one?
A: Of course, we can provide a sample for you.
Q: What is the shipping port?
A: Shanghai or Ningbo Port.
Q: How can I get the quotation?
A: You need to send up information, we will let our regional sales to contact with you, and the details you should to give: email address, telephone number, material, size, input, Load capacity, quantity, color, speed or frequency, etc
