JIECANG High Load Long stroke Tubular Linear Actuator with Wireless Remote Control
- Category: >>>
- Supplier: Zhejiang Jiecang Linear Motion Technology Co. Ltd.
Share on (1600427786088):
Product Overview
Description
Products Description
Features
1. DC 24V permanent magnet motor
2. The maximum thrust is 8000N, the maximum pull is 8000N
3. The shell color is off-white
4. Protection IP54
5. Aluminum alloy outer tube and inner tube, beautiful and corrosion-resistant
6. Low noise, the average noise level is lower than 48dB (environmental noise≤40dB)
7. Built-in electronic limit switch
8. Certification: CE
2. The maximum thrust is 8000N, the maximum pull is 8000N
3. The shell color is off-white
4. Protection IP54
5. Aluminum alloy outer tube and inner tube, beautiful and corrosion-resistant
6. Low noise, the average noise level is lower than 48dB (environmental noise≤40dB)
7. Built-in electronic limit switch
8. Certification: CE
Usage
Max 10% or 2 minutes continues use followed by 18 minutes not in use
Ambient temperature: +5 º to +40 º
Matching control box: JCB35K,JCB35K2
Company Profile
FAQ
Q: Do you get the relevant certifications?
A: Yes, so far, we have got certification of CE, TUV, UL, PSE, KC, SAA, ROSH, ISO9001:2015, ISO14001:2015 and so on.
Q: May I have a sample order before bulk one?
A: Of course, we can provide a sample for you.
Q: What is the shipping port?
A: Shanghai or Ningbo Port.
Q: How can I get the quotation?
A: You need to send up information, we will let our regional sales to contact with you, and the details you should to give: email address, telephone number, material, size, input, Load capacity, quantity, color, speed or frequency, etc
A: Yes, so far, we have got certification of CE, TUV, UL, PSE, KC, SAA, ROSH, ISO9001:2015, ISO14001:2015 and so on.
Q: May I have a sample order before bulk one?
A: Of course, we can provide a sample for you.
Q: What is the shipping port?
A: Shanghai or Ningbo Port.
Q: How can I get the quotation?
A: You need to send up information, we will let our regional sales to contact with you, and the details you should to give: email address, telephone number, material, size, input, Load capacity, quantity, color, speed or frequency, etc
