1. DC 24V permanent magnet motor 2. The maximum thrust is 8000N, the maximum pull is 8000N 3. The shell color is off-white 4. Protection IP54 5. Aluminum alloy outer tube and inner tube, beautiful and corrosion-resistant 6. Low noise, the average noise level is lower than 48dB (environmental noise≤40dB) 7. Built-in electronic limit switch 8. Certification: CE
Usage
Max 10% or 2 minutes continues use followed by 18 minutes not in use
Ambient temperature: +5 º to +40 º
Matching control box: JCB35K,JCB35K2
