5CH USB Plastic OEM Network High Definition NVR

Specification

Video/Audio Input

Video Input

40-ch

Audio Input

1-ch, 3.5mm

Network

Incoming Bandwidth

300Mbps

Outgoing Bandwidth

200Mbps

Mobile Software

P2P

Internet Protocol

TCP/UDP/HTTP/MULTICAST/UPnP/DHCP/PPPoE/DDNS/NFS/FTP/NTP/HTTPS/RTSP/SMTP/HTTPS/SADP/SNMP

Email

Activated by Alarm

ANR

Y, Auto download video from camera SD card, Which was stored when disconnnection (Only Support Tiandy ANR IP Camera)

Advanced

Remaining Bandwidth Display, Flow Monitor, Capture Package

Video/Audio Output

HDMI Output

1-ch Resolution：3840×21602560×1600，2560×1440，1920×1080，1280×720，800×6001024×7681366×7681440×900 1280×800

VGA Output

1-ch Resolution: 1920×1080，1280×720，800×6001024×768，1366×7681440×9001280×800

Recording Resolution

16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Audio Output

1-ch 1×RCA and 1×3.5mm

Synchronous Playback

16-ch 1080P/16-ch 720P/16-ch 4GIF

Decoding

Compression

H.265, H.264H

Live View/Playback

16-ch 4CIF/16-ch 720P/16-ch 1080P/4-ch 4K/2-ch 12MP simultaneous playback, 1/16 to 512 times speed

Display Split

1/3/4/6/8/9/10/13/16/20/25/36/40/64

E-Zoom

Y

Hard Disk

SATA

2SATA for 2 HDDs (Hot Swap)

eSATA

Y

Capacity

Up to 10TB Capacity for Each HDD

NTFS Files System

Y

HDD Management

Group and Quota,Customized Recording Days

Attributes

Read-write, backup, redundant, read-only

Detection

Support SMART hard disk detection technology

One-click recording

Y

Recording cycle strategy

Support three modes: loop recording, non-loop recording, and non-alarm recording priority coverage

External Interface

Network Interface

2 100/1000Mbps Self-adaptive Ethernet Interfaces

Serial Interface

2 x RS-485, 1 x RS-232

USB Interface

1x USB3.0, 1x USB2.0

Alarm In/Out

16/1

Advance

NAS

NFS Protocol

Plug and Play

Y, Only for Tiandy Cameras

Image Flip

Y, Only for Tiandy Cameras

Hot Standby

N+M

Corridor Mode

Y, 16:9 to 9:16, Only for Tiandy Cameras

Video Analytics(VCA)

Motion detection, occlusion alarm, video loss, key area coding, mixing line, double mixing line, perimeter, item left, item lost,
wandering, running, alert, helmet detection, linkage tracking, face detection snapshot, license plate recognition , On-duty
detection, crowd gathering, illegal parking, parking space guards, video virtual focus diagnosis, video scene change diagnosis,
audio signal loss detection, audio signal anomaly detection, panoramic tracking, face statistics, passenger flow statistics, face
retrieval , Behavior retrieval, license plate retrieval, alert retrieval, helmet retrieval

Trigger Recording

Manual/Timing/Port Alarm

Smart Recording

Set Different Recording Bite Rate for Different Time

One Key Control

Intercom, Recording,add

Video Encryption

Y

Records Tag

Y

Onvif

Onvif(Profile S)，GB/T28181

General

Language

English

Simplified Chinese

Power Supply

DC12V 5A

Working Temperature

-10℃～55℃

Working Humidity

10 % ~ 90 %

Chassis

1.5U

Dimensions

75mm×440mm×347mm

Weight

6Kg (without HDD)
