item | value |
Warranty | 1 year |
Type | Metal Check Valves |
Customized support | OEM, ODM, OBM, Software reengineering |
Place of Origin | China |
Shanghai | |
Brand Name | POLYGON |
Model Number | CGA-540 |
Application | Medical Gas |
Temperature of Media | High Temperature |
Power | Pneumatic |
Media | Oxygen |
Port Size | PZ27.8 |
Structure | Control |
Working pressure | 2265PSI |
Worked pressure | 15.6MPa |
DN | 4mm |
Outlet Thread | CGA540 |
Medium | Oxygen Nitrogen Air |
Taper thread | 3:25 |
Body material | HPb59-1 |
Standard | GB8335 |
Safety device | 3775PSI |
Safety pressure | 23.4~26MPa |
