MS03low speed high torque hydraulic motor
Characteristics details of MS83
Torque | |
| Maximum (Nm @ 100 bar) | 6630 |
| Maximum (lb.ft @ 1000 PSI) | 4920 |
Speed | |
| Maximum (RPM) | 210 |
Power | |
| Maximum (kW) | 41 |
| Maximum (HP) | 55 |
The maximum displacement | |
| cm3/rev. | 934 |
Cu.in/rev. | 57 |
The maximum pressure | |
bar | 450 |
PSI | 6530 |
Displacement Available | |
1C | √ |
2C | √ |
3C/4C | × |
| Wheel motor | √ |
Shaft motor | |
Male splined Shaft | × |
| Female Splined Shaft | × |
| Dual Sprocket | × |
| Shrink Disk | × |
| Pinion | × |
Brake | |
| Emergency Brake | √ |
| Service Brake | × |
| Parking Brake | √ |
| Hydrostatic Boosted Brake | × |
Anti-Skid | |
| Integrated Anti-Skiding (Twin-Lock) | √ |
Functions | |
| Wheel Drive | √ |
Track Drive | √ |
Drum Drive | √ |
Rack & Pinion Drive | √ |
Wheel Rail Drive | × |
Propeller Shaft Drive | × |
Slew Drive | √ |
| Winch Drive | √ |
Conveyor Drive | √ |
Auger / screw Drive | √ |
Cutter Drive | √ |
Mixer Drive | √ |
Pump Drive | √ |
Tools Drive | × |
Vibration | × |
Completely Replace of Poclain








(1) Are you a trading company or factory?
We are factory with professional engineers, If you have any question,we will give you a satisfied answer.
(2) What's the address of your factory?
In Shanghai.
(3) Which payment terms do you accept?
We accept L/C,T/T,D/A,D/P
(4)What is the delivery of your products?
One month.
(1) High performance rotary group with well-proven spherical control area offering the following advantages, self-centering
(2) Low periph-eral speed
(3)High efficient.
(4)Long service life robust rolling bearing.
(5) Drive shaft will support radial loads.
(6) Low noise level.
(7)High duty roller bearing for intermettent high pressure operation.
(8)For continuous duty hydrostatic are availabe.
(9)Excellent starting characteristics.
(10) High power density
(11) Optional mounting position
This is just one of our products. We provide a complete set of transmission system solutions and provide customization according to your needs.If needed please contact us
