Product Overview
Description
Products Description
DX Model Voltmeter Lcd Display Digital Ampere Meter Voltage Meter
Model | Power supply | Measurement range | Code | |||
DX2F-AV | DC 24V | AV:0.2V/2V/20V/200V/600V | B0173DX01 | |||
DX2F-AA | AA:2mA/20mA/200mA/2A/20A/200A | B0173DX01 | ||||
DX2F-DV | DV:0.2V/2V/20V/200V/600V | B0173DX01 | ||||
DX2F-DA | DA:2mA/20mA/200mA/2A/20A/200A | B0173DX01 | ||||
DX3/4/7/8/9-AV | AC 220V | AV:0.2V/2V/20V/200V/600V | B0148DX01 | |||
DX3/4/7/8/9-AA | AA:2mA/20mA/200mA/2A/20A/200A | B0148DX01 | ||||
DX3/4/7/8/9-DV | DV:0.2V/2V/20V/200V/600V | B0148DX01 | ||||
DX3/4/7/8/9-DA | DA:2mA/20mA/200mA/2A/20A/200A | B0148DX01 | ||||
Note: DX3/DX8 DC24V power supply to be ordered. DX2F AC current range is only available for models below 2A, above AC 5A to be ordered. | ||||||
Input | Please refer to the range description |
Accuracy | ±0.5%F.S ±2Digits |
A/D switch | Double integral |
Sampling rate | About 2.5times/second |
Input impedance | Please refer to the range description |
Display range | 0~±1999,Decimal point can switch through pin of PCB board. |
Display | 3 1/2 digits red LED 0.56 inch |
Overflow indication | Display“1”or“-1” |
Environment | 0℃~50℃ 35~85%RH |
Storage environment | -20℃~60℃ 35~90%RH |
Power | AC 220V 50Hz,DC 24V |
Power consumption | ≤3W |
Dielectric strength | AC 1500V 1min 50Hz |
Insulation strength | 100MΩ DC 500V |
Dimension | Pls refer to the mounting drawing |
Vibration | Sweep-frequency vibration:10~50Hz |
Weight | 0.5kg |
Promotion
Company Profile
Recommend Products
FAQ
Q1.Can you produce according to the samples or drawings?
Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q2.What is your terms of payment?
Usually,we accept T/T, irrevocable L/C at sight. For regular orders, Terms of payment 30% deposit, full payment before delivery the goods.
Q3.What is the lead time?
For standard models, lead time is about 3~5 days after order confirmed and payment received.
For OEM orders, the delivery is about 2~3 weeks after data confirmed and payment received.
Q4.What is your terms of packing?
Under TOKY brand, the standard packing is 1pc item in a colour box or brown inner box, then into standard export carton.
For OEM order, usually 1pc item in a brown inner box, then into standard export carton.
Q5.What is your terms of delivery?
We accept EXW,FOB,CIF,etc. You can choose the one which is the most convenient or cost effective for you.
Q6.How to solve the quality problems after sales?
Take photos or videos of the problems and send to us.
We will make a satisfied solution for you within 24 hours after we confirm the problems.
Q7.Do you have any MOQ limit for the order?
Low MOQ, 1pc for sample checking is available.
Q8.Is it OK to print my logo on the product?
Yes, OEM service is available.
Please confirm with our sales team formally before production and confirm the design firstly based on our sample.
Q9.Are you manufacturer or trading company?
We are manufacturer for over 30 years. Welcome to visit our factory at anytime.
