SPECIFICATION FOR CNC LATHE MACHINE H36
| Max.swing over bed | mm | 360 |
| Swing over cross slide | mm | 110 |
| Max.processing length | mm | 250 |
| X/Z axis travel | mm | 320/250 |
| spindle nose | A2-5 | |
| spindle bore | mm | 48 |
| Drawing hole diameter | mm | 40 |
| Max,spindle speed | rpm | 2500/4000 |
| Chuck size | in | 6 |
| Spindle motor | kw | 4 |
| X/Z axis repeatability | mm | ±0.003 |
| X/Z axis feed motor torque | N.m | x:4 z:4 |
| X/Z rapid traverse | m/min | 15/15 |
| Tool post type | gang type tool post | |
| Cutting tool shape size | mm | 20x20 |
| Guide form | linear guide way | |
| Total power capacity | KVA | 8 |
| Machine dimension | mm | 2000x1400x1580 |
| Net.weight(about) | kg | 1500 |
cnc lathe use
Automatic CNC lathe machine, metal CNC lathe machine, CNC lathe, automatic CNC lathe, popular CNC lathe is suitable for producing metal , plastic etc in shaft and plate shaps, could turn various threads, circle cone, circle arc, inside and outer side of revolved body. It is widely used in sanitary, valve, electrical appliance, instrument, automobile, motorcycle, bearings etc.
cnc lathe features
Sharing the concept of " the creation ,the innovation,and sharing co-prosperity", Pulute unswervingly pursuits the target of " first-class products, first class service, first class effiency", making efforts to creat greater value for the customers.
The Pulute CNC machine, at high startingpoint and of high level,is close to the customer's innovation, research and development, could meet the customers' max demand. The Pulute CNC machine are widely used in lots of large country enterprises, some domestic authoritative institute, aviation aerospace and other military industrialenterprises, at the same time , are exported to Europe,America southeast Asia and other countries and regions, and recieved user's consistent high praise.
Packaging Details PLY wooden case with steel base

Before order, please kindly inform the following,
1.Q: Which trade term I can choose?
A: You can choose FOB,CIF, DDU or other terms. You can book ship or I can book ship for you.
2.Q: How can I get quotation from you?
A: You can make the inquiry online on Alibaba, or send email to us. It is better if you can tell what is your detailed request information. We will reply to you within 2 hours on work days, and within 24 hours on holiday.
3.Q: how can I make the payment?
A: We can make the deal on Alibaba online platform, you can pay by T/T or Credit card. You can also pay to my company business bank account. You can also choose L/C or other way.
4.Q: How long does it take to get machine?
A:It takes about 25 days.
