Proper Price Top Quality Popular Sanitation Compactor Garbage Electric Truck Rear Loader
- Category: >>>
- Supplier: Nanjing Skywork Intelligent Technology Co. Ltd.
Share on (1600431136879):
Product Overview
Description
Products Description
Electrical configuration | Battery | 72V 210AH Lead-acid maintenance-free battery | |
Motor | 72V 5.5KW DC traction motor | ||
Controller | Intelligent controller self-protection function, anti-electromagnetic interference, anti-speeding, start delay and reverse deceleration and other safety protection functions | ||
Charger | High frequency intelligent 72V/30A charger | ||
Body configuration | Cab | Fully enclosed cab with metal frame, with panoramic tempered glass, wipers, headlights, tempered glass, radio, instrumentation, standard door | |
Seats | Plastic bus seat | ||
Side-view mirrors | No blind spot side-view mirrors | ||
Lights and signals | Dual LED Headlights + Turn Signals + Brake Lights + LED Engineering Warning Lights + Eddy Current Horn + Reversing Alarm | ||
Hydraulic mechanism | Single-cylinder double-chain lifting mechanism device, inner flap + outer flap turning mechanism | ||
Vehicle box | High-quality high-strength profile frame, with 2mm cold-rolled steel plate, equipped with compression mechanism | ||
Paint and color | Famous brand vehicle paint, the color can be customized | ||
Front and rear axles | Connected integrated electric differential rear axle, 3000kg load-bearing | ||
Vehicle frame | The main beam is made of GB # 12 channel steel with internal support to strengthen the structure | ||
Tire | Radial vacuum tyre,Wear-resistant and long service life | ||
Braking system | Vacuum assist + front and rear drum two cylinder hydraulic system + parking brake | ||
Steering mode | EPS power steering system+circular steering mechanism | ||
Speed control system | Continuously variable transmission (direct motor drive) | ||
Product advantages
1. Adopts streamline shape, high-grade FPR materials, smooth lines, strong and durable, novel and beautiful.
2. One person can complete loading and unloading of trash can and rear box, both are hydraulically controlled.
3. Fully enclosed box structure can effectively ensures prevent the secondary throwing of liquid waste.
4. The tire adopts Radial vacuum tyre, which is wear-resistant and has a long service life.
5. Mechanical steering system, simple and reliable.
6. The chassis adopts the structure of the miniature car chassis, and the front and rear driving hydraulic brakes have good stability and safety.
7. By controlling the button can realize the functions of lifting and compressing the scraper cylinder, lifting and lowering the trash can and box.
8. Lithium battery is optional for this model.
2. One person can complete loading and unloading of trash can and rear box, both are hydraulically controlled.
3. Fully enclosed box structure can effectively ensures prevent the secondary throwing of liquid waste.
4. The tire adopts Radial vacuum tyre, which is wear-resistant and has a long service life.
5. Mechanical steering system, simple and reliable.
6. The chassis adopts the structure of the miniature car chassis, and the front and rear driving hydraulic brakes have good stability and safety.
7. By controlling the button can realize the functions of lifting and compressing the scraper cylinder, lifting and lowering the trash can and box.
8. Lithium battery is optional for this model.
Application:
Widely used in communities, parks, schools, hospitals, hotels, restaurants, canteens, and sanitation municipalities and large and medium-sized factories and mines to carry domestic waste and medical waste collection and transfer.
More Products
Company Profile
Why Choose Us:
Nanjing Skywork Intelligent Technology Co.,Ltd have been in electric vehicle business for more than 15 years, can provide valuable suggestion and support to your purchasing and your business.
4 Production Lines with Production Capacity of 50000 units yearly
Our factory has 4 production lines, more than 60,000 square meters, each individual vehicle is 100% tested and evaluate goods prior to shipping. International Recognition With ISO9001-2008,ISO14001 , OHSAS18001 Healthy Safety Certification And CE.
4 Production Lines with Production Capacity of 50000 units yearly
Our factory has 4 production lines, more than 60,000 square meters, each individual vehicle is 100% tested and evaluate goods prior to shipping. International Recognition With ISO9001-2008,ISO14001 , OHSAS18001 Healthy Safety Certification And CE.
Exported to more than 60 countries around the world.
Due to our reliable quality and competitive prices, our electric vehicles have been exported to more than 60 countries around the world, and are widely used in golf courses, hotels, resorts, parks&garden, campus, stations, airports, residential communities, shopping centres, narrow street and etc.
12 Categories 100 models for different applications
We have 12 different categories and more than 100 models: Electric Golf Carts, Electric Street Cleaning Vehicles, Electric Garbage Sorting Vehicles, Electric Street Suction and Sweeper Vehicles, Electric Street Washing Vehicles, Electric Street Cleaning Transport Vehicles, Electric Grabage Transfer Vehicles, Electric sewage suction vehicle, Electric Fire Trucks, Electric Patrol Vehicles, Electric Sightseeing Vehicles, Can be licensed pure electric vehicles, and etc. Moreover, we support OEM/ODM orders, customize electric vehicles as per customer's request at reasonable cost, short lead time and high quality.
Due to our reliable quality and competitive prices, our electric vehicles have been exported to more than 60 countries around the world, and are widely used in golf courses, hotels, resorts, parks&garden, campus, stations, airports, residential communities, shopping centres, narrow street and etc.
12 Categories 100 models for different applications
We have 12 different categories and more than 100 models: Electric Golf Carts, Electric Street Cleaning Vehicles, Electric Garbage Sorting Vehicles, Electric Street Suction and Sweeper Vehicles, Electric Street Washing Vehicles, Electric Street Cleaning Transport Vehicles, Electric Grabage Transfer Vehicles, Electric sewage suction vehicle, Electric Fire Trucks, Electric Patrol Vehicles, Electric Sightseeing Vehicles, Can be licensed pure electric vehicles, and etc. Moreover, we support OEM/ODM orders, customize electric vehicles as per customer's request at reasonable cost, short lead time and high quality.
200 patented technologies, 10 new models and 20 innovative technologies every year
The company established a cooperative research relationship with Hefei University of Technology, hire 8 professors and doctors as consultants for the company's technical team, Set up "Electric Sanitation Vehicle Engineering Technology Research Center", Won the title of "Provincial Enterprise Technology Center", The distinguished associate professor is the dean of the Technology Research Institute
Production Line
Exhibition
Certifications
Customer Photos
15+ Years EV Expertise
More than 15 years experience in electric vehicles. With that expertise, we can help you grow your business.
Life-time Spare Parts Supplies
In the life-time of the vehicles or maximum within 5 years we stop the production of any model, we still supply the spare parts for after service
One Year Warranty
We provide 13 months warranty to the electric vehicles from the shipping date. We will cover the labor cost for any warranty issue.
Flexible Payment Terms
We offer different payment terms to different customers according to customer's special request, in order to support your business.
Support customize
Has its own research institute, hire 8 professors and doctors as consultants for the company's technical team, can customized the goods according to your requirements.
7*18*360 Service
We provide 360 days a year, 7 days a week and 18 hours a day services, can handle your problems in time
FAQ
Q1. Do you accept to customize the vehicles as per our special request?
Answer: Yes, we customize vehicles as per customer's speical request with reasonable cost and lead time, as long as the customization is not related to the chassis modification.
Q2. What is your warranty term?
Answer: We provide 1 year warranty. And for any failed part under warranty, if it can be repaired at your side and the repair cost is lower than the valve of the part, we will cover the repair cost; otherwise, we will send replacements and cover the freight cost if any.
Q3. Do you provide after service spare parts?
Answer: Yes, we provide all the spare parts to our vehicles, even 5 years after we stop the production of the vehicle. For your easier working to select the spare parts, we also supply parts manual.
Q4. Do you provide technical support?
Answer: Yes, we provide technical support by email and phone. If necessary, we can also send our engineer to your place.
Q5. Do you provide vehicle assembly service if we buy the vehicles in SKD or CKD way?
Answer: When the vehicle is in SKD way, the reassembly is just bolt and nut work, it is not difficult at all. Unless you have the assembly capability, we do not sell the vehicles in CKD way. If you do have bigger volume, we can send our people to give instructions.
Q6. Do you accept OEM order?
Answer: Yes, as long as the order quantity is reasonable (yearly 300-500 units), we will accept.
Q7. What are your terms to be your agent/dealer in my country?
Answer: We have several basic requirements, firstly you shall be in electric vehicle business for some time; secondly, you shall have the capability to provide after service to your customers; thirdly, you shall have the capability to order and sell
reasonable volume of electric vehicles.
Q8: What is your payment term?
Answer: For new customers, our typical payment term is ‘T/T 30% deposit against order confirmation, T/T 70% before container loading’. Irrecoverable L/C at sight is also acceptable. For old customers, our payment term can be more flexiable. Please contact us for more information.
Answer: Yes, we customize vehicles as per customer's speical request with reasonable cost and lead time, as long as the customization is not related to the chassis modification.
Q2. What is your warranty term?
Answer: We provide 1 year warranty. And for any failed part under warranty, if it can be repaired at your side and the repair cost is lower than the valve of the part, we will cover the repair cost; otherwise, we will send replacements and cover the freight cost if any.
Q3. Do you provide after service spare parts?
Answer: Yes, we provide all the spare parts to our vehicles, even 5 years after we stop the production of the vehicle. For your easier working to select the spare parts, we also supply parts manual.
Q4. Do you provide technical support?
Answer: Yes, we provide technical support by email and phone. If necessary, we can also send our engineer to your place.
Q5. Do you provide vehicle assembly service if we buy the vehicles in SKD or CKD way?
Answer: When the vehicle is in SKD way, the reassembly is just bolt and nut work, it is not difficult at all. Unless you have the assembly capability, we do not sell the vehicles in CKD way. If you do have bigger volume, we can send our people to give instructions.
Q6. Do you accept OEM order?
Answer: Yes, as long as the order quantity is reasonable (yearly 300-500 units), we will accept.
Q7. What are your terms to be your agent/dealer in my country?
Answer: We have several basic requirements, firstly you shall be in electric vehicle business for some time; secondly, you shall have the capability to provide after service to your customers; thirdly, you shall have the capability to order and sell
reasonable volume of electric vehicles.
Q8: What is your payment term?
Answer: For new customers, our typical payment term is ‘T/T 30% deposit against order confirmation, T/T 70% before container loading’. Irrecoverable L/C at sight is also acceptable. For old customers, our payment term can be more flexiable. Please contact us for more information.
