  • [1.25 400G all series optical module]1.25G SFP LX 1310nm 10Km DDM LC for commercial fiber for signal communication
[1.25 400G all series optical module]1.25G SFP LX 1310nm 10Km DDM LC for commercial fiber for signal communication
[1.25-400G all series optical module]1.25G SFP LX 1310nm 10Km DDM LC for commercial fiber for signal communication
[1.25-400G all series optical module]1.25G SFP LX 1310nm 10Km DDM LC for commercial fiber for signal communication
[1.25-400G all series optical module]1.25G SFP LX 1310nm 10Km DDM LC for commercial fiber for signal communication

[1.25 400G all series optical module]1.25G SFP LX 1310nm 10Km DDM LC for commercial fiber for signal communication

Share on (1600431539902):


Price:$8.00 - $8.50

Quantity:


Product Overview

Description







Product Features
Up to 1.25Gb/s data links
1310nm FP laser transmitter and PIN photo-detector
Up to 10km on 9/125µm SMF
Hot-pluggable SFP footprint
Duplex LC/UPC type pluggable optical interface
Low power dissipation
Metal enclosure, for lower EMI
RoHS compliant and lead-free
Support Digital Diagnostic interface
Single +3.3V power supply
Compliant with SFF-8472
Case operating temperature : 0°C to +70°C




Product Number
Data Rate（Gb/s）
Wavelength（nm）
Reach（km）
LD
Tx Power（dBm）
PD
Rx Sens（dBm）
Temperature（℃）
HXSX-1L311C
1.25
1310
10
FP
-9～-3
PIN
< -20
0~70










To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.




1. Can the price be negotiable?
Re: Yes, best price for you and depend on quantity.
2.what is the lead time?
Re: For standard products,we keep enough stock, shipping out in 1-3 days after PO confirmation.For big quantity and special products,Please check lead time with our sales representative.
