VIANS NO NC Access Control System Narrow Door Security Electric Strike Long Type European Electric Strike
- Category: >>>
- Supplier: Shenzhen Vians Technology Co. Ltd.
Share on (1600432102373):
Product Overview
Description
Specification
Product Parameter | Parameter Description |
Lock Size | 250Lx25Wx28H(mm) |
Certificate | CE/FCC/ROHS |
Input Voltage | DC12V±10% |
Working Current | 200mA |
Opening Mode | 90 Degree Swing Door |
Door Type Applicable | Wooden door , Glass door ,Metal door , Fireproof door |
Signal output | NO |
Security Type | NO OR NC |
Contact | Dry contact |
Surface Temperature | Within +20°C |
Material of Housing | Stainless steel |
Weight | 0.34kg |
Main advantage Feature
1. Bear 500kg impact pressure.
2. It is especially suitable for the metal frame with hole for directly installation.
3. Pass the 500 000 times of aging test.
4. Products pass the CE, FCC and ROHS certification.
5. Fire Test Report.
1. Bear 500kg impact pressure.
2. It is especially suitable for the metal frame with hole for directly installation.
3. Pass the 500 000 times of aging test.
4. Products pass the CE, FCC and ROHS certification.
5. Fire Test Report.
The electric strike lock has the similar working principle as the electric bolt lock, it must work with the mechanical lock, so
the range of application is small. And it is often used for ordinary wooden door, with the notch of strike sucking the bolt of
door, it can lock or open the door. By embedded installing, our products looks excellent. The electromagnetic part is made of high quality magnetic material and adopted specially technology processing, thereby there is no residual magnetism after long timeworking, then can prove the normal use of the strikes. Moreover, our strikes can support the door with 90 degree opened. At last,with hardness stainless steel material, our stike can bear 500kg impact pressure.
the range of application is small. And it is often used for ordinary wooden door, with the notch of strike sucking the bolt of
door, it can lock or open the door. By embedded installing, our products looks excellent. The electromagnetic part is made of high quality magnetic material and adopted specially technology processing, thereby there is no residual magnetism after long timeworking, then can prove the normal use of the strikes. Moreover, our strikes can support the door with 90 degree opened. At last,with hardness stainless steel material, our stike can bear 500kg impact pressure.
