Beer yeast Disc Centrifuge Separator/beer centrifuge for industrial brewery
- Category: >>>
- Supplier: Zhengzhou Toper Industrial Equipment Co. Ltd.
Share on (1600432806846):
Product Overview
Description
Product Description
DHC Disc Centrifuges is mainly used for liquid-solid separation for the material with solids content between 1% ~10% and the diameter of solid particles is bigger than 0.5μm. This machine has strong separation capability, and the separation factor is 9250. It can be operated manually,automatically and remotely. It is simple in structure and easy in maintenance.
The bowl is driven by the motor through the friction clutch and screw gear pair and rotate at high speed around the mainshaft.Stock liquid flows from the center charging inlet on the top of separator to the bottom through the charging pipe and then passes through disc seats to the space of the bowl.The bigger gravity solid phase particles in the stock liquid is settled down to the bowl's wall under the action of the centrifugal force and drained out from the residue under the control of the side bowl,the liquid phase is fully settled down to the center along the discs and drained out by the centripetal pump.
Main Features
It can realize liquid-liquid-solid separation. it can be operated manually or automatically or remotely. This machine is widely used for many industries, such as dairy, beverage, pharmacy, chemials, petrol, metallurgy and biology, etc.
Application
Beverage: Wine, tea, coffee and beer.
Juices: Vegetable juices, various kinds of fruit juices
Vegetable oil: Coconut oil, colza oil, cotton seed oil, corn oil, palm oil, soybean oil, peanut oil, rice oil, sesame oil, safflower oil,
Animal oil: Fish oil and other animal oil.
Mineral oil: Fuel oil, diesel oil, lubrication oil, transformer oil and waste oils.
Structure and principle
The bowl rotates at a high speed round the main axis, driven by a motor through hydraulic coupling and screw gear pair. stock liquid flows from the upper feeding pipe into the bowl's bottom and then will be separated through holes of disc seat. by the action of centrifugal force field, heavy liquid flows along the inner wall of discs to the inner wall of the bowl, after up flowing along them, it will be discharged by the heavy liquid pump, the light liquid will be done by the light liquid pump, which flows along the inner wall of discs into centre pipe and then up to high liquid outlet. the larger solid phase particles left will sedimentate on the bowl's wall and then will be discharged, controlled by the sliding bowl, out of the sediment outlet.
Company
About Toper
Zhengzhou Toper is the leading suppiler of industrial equipment in China,and also the professional exporter and service provider of filter and separation equipment.
We focus on full service for filtering project from design to after-sales service and fast supply of spare parts.
Capability:
The leading supplier of industrial equipment in China.
The professional exporter and service provider of filter and separation equipment.
Our company supplies various types of filter press,centrifuge and relevant parts.
All products of Toper:
1. Program-controlled automatic filter press
2. Membrane filter press
3. Hydraulic compress filter press
4. Mechanical compress filter press
5. Jack filter press
6. Cast iron plate and frame/chamber filter press
7. Stainless steel plate and frame filter press
8. Round plate filter press
9. Cotton cake filter press
10. Cardboard filter press
11. DY belt filter press
12. DYX high pressure belt filter press
13. DNY rotary drum thickning/dehydrating belt filter press
14. Triple-belt thickning and dehydrating filter press
15. SS type three-foot upper discharge centrifuge
16. SD type three-foot and filter bag hoist discharge centrifuge
17. PD type filter bag hoist discharge centrifuge
18. Centrifuge of up discharge, three foot, clean series SSB, SB
19. SX type manual top discharge centrifuge
20. PS type manual top discharge centrifuge
21. SGZ type automatic scraper bottom discharge centrifuge
22. PGZ type scarper bottom discharge centrifuge
23. LW series decanter centrifuge
24. Tubular centrifuge
25. Multi-layer stainless steel frame filter
26. Bag filter
27. Diatomite filter
28. Filter late
29. Filter cloth
30. Vacuum disc filter
Other centrifuges
LW series decanter centrifuge
Tubular centrifuge
PD type filter bag hoist discharge centrifuge
SS type centrifuge
FAQ
Q1: What is the Warranty for the machines?
A1: 12 months for free.
Q2: When can I get the price?
A2: Within 24 hours, if urgent, please directly call us.
Q3: Whether the machine price can be more discount?
A3: In general, our MOQ is 1set with very reasonable price, but if large order, we also can apply
to our Manager to appropriately give you a little discount.
Q4: How to ask quotation?
A4: Please note us what tpye of materials, and how many tons of materials you want to treat
per day or per hour, then we will send you quotation as soon as we can.
Q5: How long will it take to receive my products?
A5: As a general rule, it will take one 15-30 days for us to produce.
