Product Overview
Description
Oiml Certificate D2008 Waterproof Weighing Indicator Stainless Steel Indicator
Product Description
Applications
This weighing indicator is widely used in floor scales, truck scales, track scales and the other weighing instrument with 1-8 load cell.
Features
- A/D conversion with readability 1/30000
- Zero-tracking, Zero setup (auto/manual)
- Daily reports or classification reports are available to be printed auto/manual
- Able to save 512 weighing records, 255 truck ID and 100 records of goods
- Standard RS232 communication interface
- Able to connect assigned thermal printer
- Counting function with unit data save protection in case of power off
- Alarm for low battery and auto power off when low battery
- KG/LB switch function
Parameters
1.Type | D2008 (H)(AC), D2008(HP)(AC), D2008(HP1)(AC) |
2.Digital load cell interface | Communication mode RS485 Signal transmission distance 30M when connected with 12 load cells,pls contact us if you need further Transmission baud rate 9600,19200bps Excitation power DC12~14.8V Digital interface ability ≤16 digital load cells |
3.Display | 7 digits of LED,7 digits of status symbols |
4. Keyboard | Number Keys 0 ~ 9 Function keys24 pcs(10 of 24 are combined with Number keys) |
5.Clock | display year, month, date, hour, minute and second, leap year and leap month automatically. |
6.Scoreboard display interface (electric isolated with load cell interface) | transmission mode: current loop and RS232 Transmission baud rate: 600bps |
7.Serial communication interface (electric isolated with load cell interface) | transmission mode: RS232 Baud rate: Options of 600/1200/2400/4800/9600/19200 |
8.Printing interface (electric isolated with load cell interface) | With standard parallel printing interface, which can be connected with the wide line printers , such as ESPON LQ-300K+Ⅱ,ESPON LQ-300K,ESPON LQ-300K ,ESPON LQ-680K ,ESPON LQ-730K ,ESPON LQ-1600K(+),KX-P1131,KX-P1121,DS-300 |
9.Data storage | can store 1,000 groups of vehicle numbers and tare weight, 1500 groups new weighing records, 300 groups uncompleted weighing records, 6 groups overload records. |
10. Operating environment | Power input : AC 220V 50HZ DC 12V Operating temperature: 0℃ ~ 40℃ Storage temperature : -25℃ ~ 55℃ Relative humidity : ≤85%RH |
Certifications
Our Company
Taian Zhonghang weighing Apparatus Co., Ltd is a professional large-scale manufacturer of industrial weighing equipment in China. We started as a truck scale and load cell manufacturer and now 0ur products are extended to OCS electronic hanging scales and electronic platform scales,electronic floor scale,crane scale,load cell ,etc.
