CE ISO (N) Single Use Push button Smoke evacuation Handle Electrosurgical Pencil

Product Code

PS07-K70GY

Description

Smoke Evacuation Pencil with Holster

70mm  Non-stick Teflon Coated Blade electrode

3.0m(10 ft) Tubing with 22mm female connector

3.0m(10 ft) Cable with 3-prong plug

Product Function

Medstar smoke evacuation pencil, the ultimate combination of electrosurgery and removal of hazardous smoke in one instrument. Press “CUT/Yellow” button for cutting.  Press “COAG/Blue” button for coagulation.

Style

Button switch

Cable length

3m (5m length cable are also available )

Plug type

3-prong plug

Electrode type

70mm Non-stick Teflon coated blade electrode

Electrode shaft

Diameter is 2.36mm, the end of electrode shaft exposed 16.5mm

Device Classification

Class IIb

Sterilisation Method

EO

Product Shelf Life

3 years from date of sterilisation

Packaging

1PC/ TYVEK Pouch, 20PCS/ Box, 40PCS/Carton

Compatibility

Compatible with various types of electrosurgical generators.

Customized

OEM service can be available

Materials Data

Latex Free, BPA Free, Phthalate Free

Certifications

CE, ISO 13485 from TUV
